Pc Real Time Audio Spectrum Analyzer,sound Level Meter,polarity Tester, Rta-168b

US $319.95

default, default, Singapore
Feb 24th

Open on mobile:
QR code

RTA-168B-----PC Based Real Time Audio Spectrum Analyzer, Sound Level Meter, Distortion Analyzer, Polarity Tester with Multi-Instrument (Standard) Software License (Powered by Multi-Instrument, download the 21-day fully functional FREE trial at: www.virtins.com/MIsetup.exe and try it out with your computer sound card!) RTA-168B is a precision PC based real time audio spectrum analyzer, sound level meter, distortion analyzer, polarity tester... All its components can be packed into the small black soft pouch case provided and be carried together with your laptop or netbook. It is an indispensable tool for audio or acoustic measurements in both field and laboratory. Application examples are frequency response, distortion measurement and polarity test of a loud speaker, room/car equalization, noise monitoring and analyzing, etc. Combined with the computing power of a modern PC and the powerful virtual instrument software "Multi-Instrument", RTA-168B provides unbeatable performance-to-price ratio compared with any other types of RTA. Furthermore, Multi-Instrument software upgrade for the same license level is FREE for life. RTA-168B Manual can be downloaded at: http://www.virtins.com/VT-RTA-168-Manual.pdf Product page: www.virtins.com/VT-RTA-168.shtml 1. Package Contents (1) Measurement microphone: EMM-6 and its accessories (a windshield and a microphone clip) (2) XLR-to-USB Converter: VT XLR-to-USB Pre (3) USB cable (1.5 m) (4) CD (contains the copy-protected Multi-Instrument Software) (5) USB hardkey (contains a Multi-Instrument Standard License) (6) Audio Test CD (contains a list of audio test tones and noises) (7) 1/8” TRS cable (1.8m) (8) Black Soft Pouch Case (9) Individual Sound Level Calibration Data (10) Individual Microphone Response Calibration Data 2. Specifications (1) Overall VT RTA-168 Specifications Frequency Range 20Hz ~ 20kHz Sampling Rate 44.1kHz / 48kHz Bit Depth 16 Bit Number of Input Channels 1 Frequency Accuracy 0.01% Frequency Weighting Flat, A, B, C, ITU-R 468 Time Weighting Linear, Exponential (Equivalent continuous sound level (Leq) fully complies with IEC61672) Sound Level Measurement Range 25dB ~ 110dB, adjustable through both the hardware gain switch and software gain slider. Recalibration is not required after the gain setting changes. Sound Level Measurement Accuracy +/- 0.3 dB at 94dB, 1kHz after calibration Sound Level Calibration Calibrated using Type 1 Sound Level Calibrator Octave Analysis 1/1,1/3,1/6,1/12,1/24,1/48, 1/96 (Complies with IEC61260) Other Functions THD, THD+N, SINAD, SNR, SMPTE IMD, DIN IMD, CCIF2 IMD, Frequency Response, etc. Much more functions are described in the software manual. System Requirements Windows XP/VISTA/7/8, 32 bit or 64 bit. Minimum Screen Resolution: 1024 ? 600 (2) Measurement Microphone EMM-6 Specifications Transducer Type 6mm Electret Condenser Polar Pattern True Omni-directional Element Low Noise FET Input reduces low-frequency distortion Frequency Response 18Hz~20kHz Sensitivity (at 1kHz into 1kW) 10mV/Pa (-40dBV/Pa) Impedance 200W between Pin 2 and Pin 3 Max. SPL (1kW load) 127dB (THD<1%, 1kHz) Connector Gold plated 3 pin male XLR Finish Rugged Metal Construction, Silver finish Weight 144g Signal-to-Noise Ratio 70dB A-weighted Power Supply 15~52V Phantom Dimensions F21.0 ? 193.0 mm Environmental Conditions Temperature: -10°C ~ +50°C Relative Humidity: 0~95% RoHS Compliance Calibration Individually calibrated. Calibration file included. EMM-6 Typical Frequency Response Note: This is only a typical frequency response chart. EMM-6 measurement microphone was calibrated individually by its US microphone manufacturer and the calibration data is included in the product package. (3)VT XLR-to-USB Pre Specifications Frequency Response 20Hz ~ 20kHz: -0.2dB / -0.1dB -3dB: 6Hz ~ 23500Hz Sampling Rate 44.1kHz / 48kHz Bit Depth 16 Bit Number of Input Channel 1 THD (1kHz, -1.9dBFS) 0.0062% THD+N (1kHz, -1.9dBFS) 0.013% SMPTE IMD (-1.9dBFS) 0.02% DIN IMD (-1.9dBFS) 0.02% IMD at 1kHz (19kHz and 20kHz, -1.9dBFS) 0.002% Dynamic Range (hardware gain switch at LO) 78.4 dB Description Studio-quality USB microphone pre-amplifier Supplies 48V phantom power for condenser microphones No special drivers required Fully balanced low noise analog front end 3-position analog gain control Compact travel size F22 mm x 144 mm long Typical Frequency Response Typical THD, THD+N Measurement Typical IMD Measurement 3. Introduction of Multi-Instrument (Standard) Multi-Instrument (Standard) is a powerful PC based multi-function virtual instrument software. It supports a variety of hardware ranging from sound cards which are available in almost all computers to proprietary ADC and DAC hardware such as VT DSO-2810, VT DSO-2820, VT DSO-2A10, NI DAQmx cards and so on. It consists of a dual trace oscilloscope, a real time spectrum analyzer, a signal generator and a multimeter, all of which can run simultaneously. For a sound card based system, software triggering is supported. It features a specially designed data acquisition approach, which is able to monitor the input signal continuously without missing any trigger event before a frame of data is collected. It has a very fast screen refresh rate (typically greater than 50 frames per second). It supports sophisticated triggering method including pre-trigger and post-trigger. Both level trigger and differential trigger are supported. For a non sound card based system, the triggering capability depends on the hardware used. Hardware triggering is supported if the hardware used supports it. Software triggering is supported if the hardware used supports data streaming. The software has a multilingual user interface, including English, French, German, Italian, Spanish, Portuguese, Russian, Simplified Chinese, Traditional Chinese, Japanese, and Korean. It has been widely used in education, scientific research, audio engineering, electronic engineering, medical diagnosis, vibration analysis, etc. The software can be downloaded for 21-day fully functional FREE trial using your sound card as the ADC and DAC device at: www.virtins.com/MIsetup.exe. Video introduction of Multi-Instrument: http://youtu.be/msx5envAgGw 4. Functions of Multi-Instrument (Standard Version) A comprehensive range of functions are provided in Multi-Instrument (Standard), including: (1) Oscilloscope Oscilloscope Mode: dual-trace waveform, waveform addition, subtraction and multiplication, Lissajous Pattern, transient signal recording, voltmeter. Record Mode: Record data to the hard disk continuously until the recording process is stopped manually or 2 gigabytes of data has been recorded, whichever is earlier. During the recording process, acquired data will still be analyzed and displayed to keep the screen updated in real time. Roll Mode: Data displayed in the Oscilloscope will shift left gradually while the newly acquired data are added from the right. (2) Spectrum Analyzer RMS amplitude spectrum, relative amplitude spectrum, octave analysis (1/1,1/3,1/6,1/12,1/24, 1/48, 1/96), frequency compensation, frequency weighting (A,B,C,ITU-R 468), moving average smoothing, peak hold, linear average, exponential average, measurement of THD, THD+N, SNR, SINAD, Noise Level, IMD, Bandwidth, Crosstalk, Harmonics, Peaks, and Energy in user defined frequency bands, phase spectrum, auto correlation function, cross correlation function. (3) Signal Generator Function generation, multitone generation, arbitrary waveform generation, burst tone generation, MLS generation, DTMF generation, musical scale generation, white noise and pink noise generation, and frequency/amplitude sweep signal generation. Fade In / Fade Out of the output signal. (4) Multimeter RMS, dBV, dBu, dBSPL, dB(A), dB(B), dB(C), Frequency Counter, RPM, Counter, Duty Cycle, Frequency/Voltage Conversion, Cycle RMS, Cycle Mean. The latter seven modes involves a pulse counting process, with the counter trigger level, hysteresis, frequency dividing ratio adjustable. 5. License information and Function Allocation in Multi-Instrument Series The full package of Multi-Instrument has six levels and five add-on modules/functions. The six levels are: Sound Card Oscilloscope (listed price US$24.95), Sound Card Spectrum Analyzer (listed price US$39.95), Sound Card Signal Generator (listed price US$24.95), Multi-Instrument Lite (listed price US$49.95), Multi-Instrument Standard (listed price US$99.95), Multi-Instrument Pro (US$199.95). The five add-on modules/functions are: Spectrum 3D Plot (listed price US$99.95), Data Logger (listed price US$99.95), LCR Meter (listed price US$99.95), Device Test Plan (US$99.95), Vibrometer (US$99.95). Note: The item here contains one USB hardkey activated license of Multi-Instrument (Standard) without any add-on modules/functions. No softkey (activation code) is provided. The software will run under the licensed mode as long as the USB hardkey (dongle) is connected to your computer before you start the Multi-Instrument software. Please refer to the function allocation matrix at: http://www.virtins.com/multi-instrument.shtml for the differences among different license levels. 6. Software Upgrade Policy Software upgrade for the same level is always FREE. When a new version is available, you can just uninstall your current version, download and re-install the new version, as long as the USB hard key is still supported by the new version. Software upgrade to a higher level can be purchased from our website at: www.virtins.com . The software license bundled within the USB hardkey is remotely upgradable. 7. Shipping We ship worldwide. The item will be shipped via registered air parcel within 24 hours after the payment is received. It will take normally about 2 weeks to reach you (e.g. USA, UK, Australia, Canada, Hongkong, Taiwan, Japan, Korea...). In some specially cases, or special places (e.g. Italy), it may take 3~4 weeks. The shipping and handling charge is fixed at US$30 for all places. Add US$19.95 for EMS delivery, it takes about 3~8 days. 8. Refund Policy One year warranty against defective materials and manufacturing defects for all hardware parts inside the package. Return of defective item is accepted for a refund within 7 days after you receive the item. For a full refund, the package must be in the same condition as received with all accessories. The returned item must be delivered prepaid by the customer. You must contact us first before you return it. We strongly recommend that you try out the Multi-Instrument software from our website first before you place your order. Please contact us if you are in doubt. Flexible Hardware Connection: Method 1 Flexible Hardware Connection: Method 2

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Virtins Technology
Model	VT RTA-168B
