Pc Usb 20mhz 2ch Oscilloscope 16channels Logic Analyzer Data Logger 3in1 Mdso-la

US $94.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

MDSO dual-channel digital oscilloscope, with "low-cost, high-performance" as the design goals. well-designed bandwidth of 20M, 48M sampling rate, 2 channels, alternating support X, Y and XY alternating pattern of two-channel virtual oscilloscope, spectrum analyzer and data recorder. Feature: Oscilloscope Specification: 1, sample rate: 48MHz; 2, the number of channels:2 3, the memory depth: 1M; 4, the voltage resolution: 1V/256; 5, high-speed USB 2.0 data transmission; 6, the minimum measuring signal input:-50V (with probe X10); 7, the measurement signal input: +50 V (with probe X10); (Probe X1 stalls, testing peak Peak 10V signaling) 8, the maximum measurement frequency (ideal): sine-15MHz square wave-5MHz; Measured values (according to the sampling theorem, theory 48MHz, but because of the increased frequency of testing, resulting in fewer sampling points, there will be distortion waveform restore) Software trigger: rising, falling, rising / falling edge, differential, rise + differential; The data logger specifications: 1, the number of channels: 2; 2, the data storage format: OSC files, CSV files (you can use Excel to directly open); 3, the sampling rate range: 0.25MHz-24MHz (specific sampling rate is determined by the computer); (Probe X1 stalls, testing peak Peak 10V within the signal to meet the commonly used voltage range) 4, the minimum measuring signal input:-50V (with probe X10); 5, the measurement signal input: +50 V (with probe X10); 6 consecutive stored waveform, and to support the global scaling and mobile viewing; 7, the support is repeatedly recorded data at the same time to load, easy waveform. The logic analyzer specifications: (1) the MDSO-the LA logic analyzer 1, the number of channels: 16 (DCH1-DCH16); 2, sample rate: 0.25M-24MHz; 3, the memory depth: Determine the size of the computer's hard drive; 4, can be continuously stored data, and support global, zoom, and mobile viewing. (2) the Selesa Logic, logic analyzer 1, the number of channels: 8 (DCH1-DCH8); 2, sample rate: 0.025 M-24MHz; 3, the memory depth: Determine the size of the computer's hard drive; 4, can be continuously stored data, and support global, zoom, and mobile viewing. 5, support for protocol analysis: SPI, I2C, CAN, UART, I2S/PCM, the DMX-512, Manchester, 1-WIRE, the Simple of Parallel, UNI / O; The software Specification: 1, you can save waveform; 2, start, pause functions; 3, move the cursor to measure the voltage and time; 4, the measured signal frequency, the average peak to peak display; 5, the convenience of Windows imitation of the kind of man-machine interface; 6, through the software interface to a variety of switching operations; (time scale, voltage scale, closed and open channels, etc.); 7, with the saved waveform zoom in and out of the window to the selected part of the observation ; 8.It support any multi-screen display to facilitate the diverse analysis of the waveform; 9.support the input waveform hardware and software triggers; 10.support the interpolation of the input waveform and equivalent sampling; 11.support the input waveform "add", "subtraction" and "phase Multiply synthesis; Rectangle, bartlett, triangular, cosine, hanning, bartlett_hanning, hamming, blackman, blackman_Harris, tukey, Nuttall, FlatTop, Bohman, Parzen, Lanczos, kaiser, gauss, dolph_chebyshev 18 kinds window 12.support plus the input waveform; support filtering of the input waveform; 13.support the input waveform Lissajous Ru graphics "," amplitude-frequency "," frequency "," logarithmic amplitude-frequency power spectrum, the logarithmic power spectrum, self-and cross-correlation analysis; 14.support in logarithmic coordinates, the input waveform amplitude-frequency "," frequency "and" several pieces of frequency, power spectrum, on the number of self- power spectral analysis. Package Included: 1 x MDSO-LA oscilloscope host 1 x USB 2.0 extension cable 2 x 40 M standard oscilloscope probe 20 x the logic analyzer test clip 1 x CD for software Note: we'll ship this item via Epacket to US, usually the delivery time is about 2-3 weeks; for other countries, we'll ship it via registered air mail of China Post, usually the delivery time is about 30-40 days. If you want express mail service, please contact us for extra postage in advance.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	MDSO-LA
Unit Type	Modules
MPN	MDSO-LA
Country of Manufacture	China
Analyzer Type	Logic Analyzers
