Pdc Sss-88 Solid State Traffic Load Switch Model 200

US $4.69

Paris, Kentucky, United States
Jan 29th

Open on mobile:
QR code

Solid State Load switch: Description: The PDC SSS-88 Solid State Loadswitch is a tri-pack solid state relay package designed specifically for the Traffic Control Industry. This unit meets NEMA specification TS1-1983, section 5 as well as the California Department of Transportation “Model 200 “ specifications. Each switch will turn it’s rated load ON or OFF within 10 deg. of the first zero cross-over point & within 5 deg. on succeeding alterations randomly timed input command signal. The electronics are enclosed in a dust resistant, metal enclosure providing mechanical protection and excellent heat sinking for the heat generating components in the circuit. The electronic components are easily accessible by removing the cover with a screwdriver. General Characteristics: Load voltage.............................................120 VAC current (max).................................. 15.0 Amps (Tungsten Filament Load) Control Signal voltage............................................. +24VDC current ............................................. 20.0 MA (max) Switching 1st alternation after..........................+10 Degrees of line voltage at the zero signal is applied. crossover point. Succeeding alterations......................+5 Degrees of line voltage at the zero crossover point. Off State dv/dt.................................................100 V per microsecond line to load resistance......................15 K Ohms Min leakage current................................less than 20 MA Isolation voltage.............................................2500 VDC Min resistance.........................................10 Meg Ohms Min Surge Current one cycle..........................................175 Amps RMS Min one second.......................................40 Amps RMS Min Life operations.........................................30 million Min Mechanical lenght...............................................8.40 inches width................................................1.74 inches height...............................................4.185 inches weight..............................................1.135 LBS WE OFFER A DISCOUNT FOR SHIPPING WHEN YOU BUY QUANITIES BASED ON WEIGHT. NEW, BUT OUT OF BOX MODULES LEFT OVER FROM CONSTRUCTION PROJECT.

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“wORKS GREAT!”
