Pemicro P&e Usb Multilink Universal

US $99.99

San Ysidro, California, United States
Jan 29th

Open on mobile:
QR code

P&E’s USB Multilink Universal is an all-in-one development interface which allows a PC access to the Background Debug Mode (BDM) or JTAG interface on Freescale HCS08, HC(S)12(X), S12Z, RS08, ColdFire V1/+V1, ColdFire V2-4*, Qorivva 5xxx, and Kinetis ARM microcontrollers. It connects between a USB port on a Windows machine and the standard debug connector on the target. The Freescale microcontrollers are supported via the multiple headers located on the USB Multilink Universal. The product photos to the left of this page show how the headers can be accessed by simply flipping open the plastic case. Ribbon cables suitable for a variety of architectures are included. Supported Freescale Devices:Kinetis (includes L-Series) Qorivva MPC5xxx ColdFire +V1/ColdFire V1 ColdFire V2/3/4 HC(S)12(X) S12Z HCS08 RS08 DSC By using the USB Multilink Universal, the user can take advantage of the background debug mode to halt normal processor execution and use a PC to control the processor. The user can then directly control the target’s execution, read/write registers and memory values, debug code on the processor, and program internal or external FLASH memory devices. The USB Multilink Universal works with P&E Microcomputer System's in-circuit debuggers and flash programmers to allow debug and flash programming of the target processor. For many of the supported processors, P&E has a set of interface libraries allowing the user to write their own Windows based application which interacts with P&E's debug interface. IAR, Cosmic, Codesourcery, Keil, Atollic, and CodeWarrior software all support the use of P&E's USB Multilink Universal to develop and debug with Freescale's Kinetis ARM devices. This interface is USB 2.0 compatible, and it is also backwards compatible with USB 1.1 ports. FEATURES: USB interface from PC to Multilink allows for fast, easy programming and debugging -- with the ease and compatibility of the USB interface. Draws power from USB interface-- no separate power supply required (draws less than 1mA from the target). Target Voltage: 1.8V-5.25V Target Frequency: 16Khz-50Mhz (applies to HCS08,RS08,CFV1, S12Z, or HCS12X only) Compatible with HCS08, RS08, HC(S)12(X), S12Z, ColdFire V1/+V1, ColdFire V2-4, Qorivva MPC5xxx, and Kinetis ARM families of microcontrollers. Kinetis support includes both the JTAG and SWD protocols Includes USB cable, Type A Male to Type B Male, 6-ft. Auto-frequency detection + trimming capabilities for HCS08 devices. Auto-frequency detection for HC(S)12(X) devices. Generates programming voltage on RESET line for RS08 devices. Includes: One (1) USB 2.0 High Speed Cable, Type A to Type B, 6-ft. One (1) 6-pin 0.100" pitch ribbon cable for connecting to RS08, HCS08, HC(S)12(X), S12Z, ColdFire V1/V1+ targets One (1) 14-pin 0.100" pitch ribbon cable for connecting to Qorivva MPC5xxx targets One (1) 26-pin 0.100" pitch ribbon cable for connecting to asynchronous ColdFire V2/V3/V4 targets One (1) 20-pin 0.100" pitch ribbon cable for connecting to Kinetis ARM targets One (1) 10-pin 0.050" pitch ribbon cable for connecting to Kinetis ARM targets (Mini-10) One (1) 20-pin 0.050" pitch ribbon cable for connecting to Kinetis ARM targets (Mini-20) Shipping to the lower USA 48 states only. Ask if you have any question.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	PEMicro
MPN	USB-ML-UNIVERSAL
Model	USB-ML-UNIVERSAL, Version C
