Phase-a-matic Pc-900-hd Heavy Duty Static Phase Converter Horsepower: 4 ~ 8

US $269.99

Flushing, New York, United States
Jun 9th

Open on mobile:
QR code

PHASE-A-MATIC Heavy Duty Static Phase Converter - Model : PC-900-HD Horsepower: 4 ~ 8 4- 8HP H/D STATIC PHASE CONVERTER -PHASE-A-MATIC Applications Runs more than one machine. Can operate 2 speed motors. Features Instant reversing. Runs 220V, 3PH equipment on 220V, 1PH power for light to moderate loads. Will produce approximately 2/3 rated horsepower. Important: How To Order… · Do Not install a larger size PHASE-A-MATIC™ or Heavy Duty series thinking it will give you more HP. The PHASE-A-MATIC™ HP range is determined by the minimum and maximum starting current applied to it at any one time. The largest motor on your machine, or the idler motor, if used, must fall within the minimum and maximum HP range marked on the PHASE-A-MATIC™. Do not add HP of the power feed, coolant pump, etc. These rely on the generator effect of the main motor. The only time you would add the HP of two or more motors together would be if they always started at exactly the same time. · For multiple motor applications, the largest motor must always start first and it must be at least 50% larger than any other motor starting on the same converter. · Two-speed motors are dual HP. Select the PHASE-A-MATIC™ with minimum and maximum HP which fall within or very close to the minimum and maximum HP of the motor. For example: A 1-1/2 HP 3,450 RPM motor is 3/4 HP at 1,725 RPM. · Some European soft-start motors draw less starting current than normal and therefore require a smaller than normal converter. Most Taiwanese motors draw greater amperage to start than normal. Therefore, for Taiwanese motors we recommend you use model #PC-600HD for 3 HP motors, model #PC-900HD for 5 HP motors and model #PC-1200 for 7-1/2 HP motor etc. Tech Tip: When To Use Heavy Duty Series PHASE-A-MATIC™ · Lathes above 3 HP not fitted with a clutch. · Air compressors (the motor pulley) must be reduced by 1/3, or a 50% larger motor must be fitted. · Long heavy starting cycles, frequent starting or instant reversing, unattended motors, if jogging is required, or if there is a chance of the motor being stalled during use. PRODUCT SPECIFICATIONS Unit of Measure each Must Buy 1 Country of Origin UNITED STATES OF AMERICA Shipping Restrictions None Brand PHASE-A-MATIC Description PHASE-A-MATIC Heavy Duty Static Phase Converter - Model : PC-900-HD Horsepower: 4 ~ 8 Model # PC-900-HD Horsepower 4 ~ 8 Weight 4 lbs. Application • Runs more than one machine.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	PHASE-A-MATIC
Model	PAM-900HD
