Phase Ii 4"horizontal & Vertical Table

US $314.79

Flushing, New York, United States
Jan 30th

Open on mobile:
QR code

PHASE II 4"Horizontal & Vertical Table 4" HORIZONTAL/VERTICAL ROTARY TABLE - PHASE II Applications Use for indexing, drilling or milling. Machining curved surfaces by utilizing circular milling. Milling and boring where close tolerances are required. Machining flat surface is set at a certain angle to a given reference. Quality control. Jig boring. Features Adjustable satin chrome dials are extremely large in diameter for easy reading. All dials are precision ground and graduated in minute and second increments as well as degrees. Totally enclosed rugged base casting, precision ground and parallel within .0006". (2) Locks provided for positive action. The worm and shaft are of one piece hardened and ground. All rotary tables are equipped with disengageable worms which affords quick rotation for indicating workpieces. Oiling facilities are provided for all moving parts. Low profile. TurntableMade of "high grade meehanite castings". Precision ground and parallel within .0006". All T-Slots are machined. Graduations are accurately cut in increments of one degree. 3 Morse Taper hole in center bore. Optional AccessoriesDividing plates have all divisions from 2 to 66 and all numbers from 68 to 132 that can be divided by 2, 3 and 5. Fits all except 6". Second vernier: 10" Gear ratio: 90:1 Adjustable tailstocks: 2 MT Benefits A convenient method of worm adjustment is provided to compensate for wear. Each table is supplied with a signed inspection certificate and an operating certificate. Note Rotary Table/Lathe Chuck Adapter Plate Ordering Information Don't know which adapter plate/lathe chuck to use with your rotary table? Use the guide below to help you determine what to buy: Rotary Table Adapter Plate Lathe Chuck 4" 4" 3" 6" 6" 5" 8" 8" 6" 10" 10" 8" 12" 12" 10" 16" 16" 12" PRODUCT SPECIFICATIONS Unit of Measure each Must Buy 1 Country of Origin Import Shipping Restrictions None Brand PHASE II Description PHASE II 4"Horizontal & Vertical Table Model # HV221-304 Price Table Description 4" Horizontal & Vertical Table Size 4" Weight 22 lbs.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Manufacturer Part Number	221-304
Part Brand	PHASE II
