Phoenix Contact Quint Power Supply Quint-ps-100-240ac/24dc/5 2938581

US $70.00

Fremont, California, United States
Jan 29th

Open on mobile:
QR code

BRAND NEW!! NEVER USED!! STILL IN FACTORY BOX!! NEVER USED!!! Don't take a chance on a "USED" Phoenix Contact Quint Power Supply Quint-PS-100-240AC/24DC/5 2938581 Product description QUINT POWER is the powerful 60 - 960 W DC power supply unit for universal use. With its wide-range input, single and three-phase versions, and international approval package, this solution is unrivalled. QUINT POWER provides reliable power supply: generously dimensioned capacitors ensure mains buffering of over 20 ms at full load. Full output power is provided by all three-phase devices, even in the event of a permanent phase failure. The Power Boost power reserve easily starts loads with high inrush currents and ensures that fuses are reliably tripped. Preventive function monitoring diagnoses impermissible operating states and minimizes downtimes in your system. Remote monitoring is provided by an active transistor switching output and a floating relay contact. All devices are idling-proof and short-circuit-proof, and are available with a regulated and adjustable output voltage of 12, 24, and 48 V DC with output currents of 2.5, 5, 10, 20, 30, and 40 A. Power supply units for use in Ex zone 2, uninterruptible solutions, AS-i power supply units, and a QUINT diode complete this comprehensive product range. Input data Nominal input voltage range 100 V AC ... 240 V AC Input voltage range 85 V AC ... 264 V AC 90 V DC ... 350 V DC AC frequency range 45 Hz ... 65 Hz Frequency range DC 0 Hz Current consumption approx. 1.6 A (120 V AC) approx. 0.84 A (230 V AC) Nominal power consumption 120 W Inrush surge current < 20 A (typical) Power failure bypass > 30 ms (120 V AC) > 130 ms (230 V AC) Input fuse 5 A (slow-blow, internal) Choice of suitable fuses 6 A ... 16 A (Characteristics B, C, D, K) Type of protection Transient surge protection Protective circuit/component Varistor Output data Nominal output voltage 24 V DC ±1 % Setting range of the output voltage 22.5 V DC ... 28.5 V DC Output current 5 A (up to 60°C) 7.5 A (with POWER BOOST) Derating 60 °C ... 70 °C (2.5%/K) Connection in parallel Yes, for redundancy and increased capacity Connection in series Yes Max. capacitive load Unlimited Active current limitation Approx. IBOOST = 7.5 A (for short-circuit) Control deviation < 1 % (change in load, static 10 % ... 90 %) < 2 % (change in load, dynamic 10 % ... 90 %) < 0.1 % (change in input voltage ±10 %) Residual ripple < 10 mVPP (with nominal values) Peak switching voltages nominal load < 30 mVPP (20 MHz) Maximum power dissipation NO-Load < 2 W Power loss nominal load max. < 14 W General Net weight 0.83 kg Operating voltage display Green LED Efficiency > 89 % Insulation voltage input/output 4 kV AC (type test) 2 kV AC (routine test) Protection class I (with PE connection) MTBF (IEC 61709, SN 29500) > 500000 h Mounting position horizontal DIN rail NS 35, EN 60715 Assembly instructions Can be aligned: Horizontally 0 mm, vertically 50 mm Electromagnetic compatibility Conformance with EMC directive 89/336/EC Noise emission EN 50081-2 Standard – Electrical equipment of machines EN 60204 Standard - Safety of transformers EN 61558-2-17 Standard - Electrical safety EN 60950-1/VDE 0805 (SELV) EN 61558-2-17 Shipbuilding approval Germanischer Lloyd (EMC 2), ABS Standard – Electronic equipment for use in electrical power installations and their assembly into electrical power installations EN 50178/VDE 0160 (PELV) Standard – Safety extra-low voltage EN 60950-1 (SELV) EN 60204 (PELV) Standard - Safe isolation DIN VDE 0100-410 DIN VDE 0106-1010 Standard – Protection against electric shock DIN 57100-410 Standard – Protection against shock currents, basic requirements for protective separation in electrical equipment DIN VDE 0106-101 Standard – Limitation of mains harmonic currents EN 61000-3-2 Standard - Equipment safety GS (tested safety) Information technology equipment - safety (CB scheme) CB Scheme UL approvals UL/C-UL Recognized UL 60950 UL/C-UL listed UL 508 UL ANSI/ISA-12.12.01 Class I, Division 2, Groups A, B, C, D (Hazardous Location) Surge voltage category III

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Phoenix Contact
MPN	2938581
Model	Quint-PS-100-240AC/24DC/5
Country/Region of Manufacture	Unknown
