Pic Development Board Pic Learning Board Microchip Atmega16a New

US $21.66

hongkong, China
Jun 9th

Open on mobile:
QR code

Description : PIC Development Board PIC Learning board Microchip ATMEGA16A Please note that buyers, and the development board to tie Development Tools USB-JTAG (emulator) which can be downloaded free drive emulation program can be USBISP downloader (download only), one of the two in order to use! Download Tool: 1. AVR emulator (emulator can be downloaded to the program) and the development board is strongly recommended to buy together. USB-JTAGICE (USB AVR emulator) Free drive USBASP program for downloading AVR chip (no need drive, plug and play) (Note Downloader can download the program can not be simulated) This product uses SMD design, optimization of the various parts of the circuit, using high-quality aluminum electrolytic capacitors Question : 1. Your this development board, is how to download the program? A: The development board can be used in two ways to download, 1, ISP interface to download 2, JTAG interface to download. You need to buy another tool. 2. Your this development board, did not see the serial, serial communication can make it? A: The development board has been omitted old DB9 serial interfaces (new computers do not have this interface, nor the notebook interface), built-in USB plug USB to serial chip to connect with PC for serial communications. Omitted, USB to serial cable. This small system board has the following advantages: 1, the chip socket: ATmega16 MCU DIP40 relatively easily accessible in the locked seat. 2. Download the way: You can use USBISP download, you can use JTAG emulator download 3, power supply: USBISP or USB-JTAG and external power supply (external power supply, can supply the power supply voltage of 5V). 4,8 Road LED (LED indicator to know the importance, in the actual doing engineering, with this indicator can be used directly working status LED indicates the program, to facilitate debugging, than with emulator oh. 5, the serial port: use the USB to serial chip for serial communication control. 6, ADC: analog-digital conversion circuit (in-band 10 AD, can be used as a voltmeter, ammeter, oscilloscope, etc.). 7, the microcontroller crystal using pluggable, always replace size, suitable for different applications and experimental applications. 8, DS18B20 temperature sensor interface, you can do temperature measurement experiment, this price does not include DS18B20 Oh, if required another shot. 9, infrared integrated receiver that can fit any infrared remote control experiment, the price also does not include the integrated receiver, and needed another shot. 10, four digital tube, digital tube display experiment can be done. 11, four separate buttons, you can do key experiments. 12,1602 LCD circuit interface, you can do LCD experiment. 13,12864 LCD experiment, you can do 12864 LCD experiment. 14, the buzzer sound can be used for experiments. 15, Bluetooth, wireless interfaces, can be used for wireless communication experiment 16, left steering interface, easy to drive steering 17, left infrared detection interface for easy and infrared docking realization of human traffic statistics. Boards and infrared detection module docking can be real crowd count, robot obstacle avoidance (with supporting program) Boards and APC220 wireless module docking, convenient wireless communication Servos connected to the development board, easy to control the robot motion (with supporting program) Boards and easy to implement voice module docking port, voice broadcast Boards and Bluetooth wireless module docking port to facilitate wireless communication (you can control the car movement, etc.) Shipping list: 1. AVR development board 1pcs 2. ATMEGA16A 1pcs (already plugged into the board) 3. Jumper 10pcs (already plugged into the board) 4. Crystal 8M 1pcs (already plugged into the board) 5. Crystal 7.7328M 1pcs 6. DVD disc 1pcs( include 3.8G data) 7. USB print line 1pcs 9, M3 pillars high 6MM + nut thread 6MM + total 4pcs (already mounted on the board) 10, Package : anti-static bag.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded/Generic
Country/Region of Manufacture	China
MPN	Does Not Apply
UPC	Does not apply
