Pic Development Kit, Open Source Examples, Free Compiler, Pic16f1827-i/p

GBP 17.99

Weymouth, Dorset, United Kingdom
Feb 21st

Open on mobile:
QR code

PIC Demonstration / Development Kit, with open source examples in MPLABX XC8 and MPASM. This item is supplied as a kit of components, the programmer is NOT included. The XC8 C compiler is a free download with MPLABX from Microchip the maker of PIC microcontrollers. This kit includes a PIC16F1827-I/P pre-programmed with the example code, a GOLD plated PCB, all components and a backlit LCD display as pictured above. Details Follow. Program with the PicKit2, or Program and Debug with the PicKit3 & MPLAB Includes:- 2 line x 16 character backlit LCD I?C temperature sensor RS232 interface Variable voltage source for analogue input stimulation 5V regulator for use with PicKit3 or stand alone operation Expansion bus PCB can mount on back of display with straight display connectors and nut/bolt/spacer kit (request this option when ordering or the kit will be supplied with parts for assembly as pictured). We include an open source example program in MPLABX XC8 C (download from link below) which displays the temperature, an 8 bit ADC value, a running loop count and outputs the temperature to the serial port. This includes C functions for I?C, LCD, serial port TX and ADC input. Other examples include MPASM serial port TX/RX and fuse configuration. Use this kit to experiment with 18 pin PIC microcontrollers (PIC16F1827 included), learn C or assembly language programming, develop and test your own ideas. Use the kit as a low cost building block for your own projects, the PCB can mount on the back of display with straight display connectors and a nut/bolt/spacer kit which is also available(see above). Just starting out? If you are a beginner you will need to download MPLABX and the FREE XC8 C compiler and also purchase a PicKit2 or PicKit3 programmer (other programmers can be used but the programming connector is pinned for the PicKit). You will also need to follow the instructions, guides and examples available from Microchip and other online sources to use these tools. Note that the PicKit2 programmer can power this demo board and program the PIC16F1827 in-circuit using the software supplied with the PicKit2, the PicKit3 uses MPLAB to program and debug the PIC16F1827 but does not provide power to the demo board, you need to supply 8 to 15V DC at 10mA with no back light enabled, or 12 to 15V DC at 100mA with the backlight enabled. You can view or download a PDF datasheet here:- http://www.cstech.plus.com/ebay/PIC_demo.pdf You can download the Open Source example files from here:- http://www.cstech.plus.com/ebay/pic_downloads.html See an assembled version of this kit in a YouTube video demo:- YouTube.com/watch PIC Development Kit video The kit will be very well packed and posted First Class in the UK, and by Airmail to the EU Business seller information DJS Electronics Ltd T/as cstech.co.uk Contact details Dave Squibb 11 Goldcroft Avenue Weymouth Dorset DT4 0ET United Kingdom Phone:01305760307 Email:sales@cstech.co.uk Registered Office: Unit 3D Dreadnought Trading Estate, Magdalen Lane, Bridport, Dorset DT6 5BU Trade Registration Number: 04917759 Value Added Tax Number: GB 000000000 Print version Terms and conditions of the sale Everything we list is in stock. Orders are normally posted within 2 working days of receipt, you will be notified if there is any reason this cannot be achived. We check orders carefully for any errors before processing and we reserve the right not to accept any order we feel contains an error. We will contact you if an error is found. Where your PayPal postage address is not a confirmed address and your PayPal and eBay postal addresses do not match, we will contact you via eBay email to confirm the correct address for delivery. All our kits are RoHS compliant and could be assembled with lead free or tin lead solder. Return policy To qualify for a hassle-free return, you must pay with PayPal and have the item shipped to a US address. The item must be returned in the same condition it was received. See terms and conditions - opens in a new window or tab. After receiving the item, open a return within Return shipping 14 days You pay return shipping
