Plans, Model 32 Pipe Tube Bending Machine. 2-1/2 Od

US $17.00

  • Saint Cloud, Florida, United States
  • Jan 31st
Open on mobile:
QR code
You are buying one large piece of paper with traces of most parts from an original MODEL 32 PIPE TUBE BENDER MACHINE. paper measures about 22" x 28" paper will have smudges and wrinkles. degree ring - traced. all four arms - traced. After you build this machine you will be able to bend..... 1/2" to 2" Sch 40 Pipe 1/2" to 2-1/2" OD Round 1/2" to 1-1/2" Square Tube 2" OD .250 wall DOM When bending 2-1/2 pipe or tube you will need hydraulics. If your using regular equipment to build this machine, for example a $200.00 drill press, you should sandwich the two arms together before you drill the holes. The holes don`t have to be perfect but each arm must be the same as the other or else the pins will not line up. You also don`t have to make the arms the same shape, the ends could be square instead of round then you can cut off the corners. sold as is.
