Pmc Contoureader Precision Contour Reader Metrology Model 150

US $5700

Englewood, Colorado, United States
Jun 7th

Open on mobile:
QR code

CounteReader Model 150 - Chart Recorder NOT Included. Sold as is picture is showing! ... the only instrument that can measure dimples on a golf ball with ±0.0002" accuracy, and draws the results 200x size! Measures small inside shapes as easily as outside contours The ContouReader by PMC Gage, Inc. is part of a new generation of precision instruments to inspect both internal and external dimensions of literally thousands of parts to guarantee the quality of your products. There are two versions of the ContouReader; a standard and new Windows-based computerized version. The ContouReader inspects everything from dimples on golf balls to turbine blades with the same repeatable accuracy to reveal any defects, deviation from specifications, or rough edges that can adversely affect product quality. The operation of the ContouReader is simple. A part is placed in a fixture, and the tracing stylus moves gently over the surface of the part, transferring the stylus arm movements into electrical voltages which are amplified and transmitted to the chart recorder or computer display. The recorder moves a pen to draw an exact duplicate of the part contour on chart paper up to 200 times its original size, and with accuracy of ±0.0002 inches on the standardized version. The computerized version will display an exact duplication of the part contour to an infinite magnification. A manual or electronic master overlay is used over the ContouReader tracing to compare for accuracy. What will you be able to see? Crest forms, root radii, flank angles, pitch diameters, and others, all in seconds on a permanent record strip chart or electronically. The electronic version can be shared via DXF or DWG format. ContouReader Tracing Speed Stylus Point Radius Stylus Hardness Stylus Pressure Accuracy Minimum Hole Size for I.D. Tracing Vertical Positioning Range of Probe(s) Stylus Horizontal Travel Maximum Vertical Stylus Travel Maximum Head Tilt Minimum Included Angle Using Standard Styli Weight Chart Recorder Magnifications on Horizontal & Vertical Axis Weight Single Stylus Model 150 4" Travel .005 ips .001" 65Rc 4 grams ±0.0002" 0.15" (with special stylus) 6" 4" 0.500 +15° -10° 26° 67° Ascending 87° Descending 155 lbs. Single Stylus Model 150 10x/20x/50x 100x/200x 38lbs
