Portable Hantek Dso8060 2ch 60mhz Handheld Oscilloscope Scopemeter 250 Msa/s

US $199.00

Melbourne, Florida, United States
Jan 29th

Open on mobile:
QR code

Hantek DSO8060 Main Features: Hantek DSO8060 is the double-channel digital oscilloscope with installed multimeter and signal source. Bandwidth is 60MHz. Real-time sampling rate is 250MSa/s. Frequency range is 1-25MHz. Multimeter mode allows user to measure AC/DC current and voltage, resistance, capacitance, continuity and test diodes.This handheld digital oscilloscope is ideal for production test, field service, research, design, education and training involving applications of analog circuit tests and troubleshooting. Hantek DSO8060 Handheld Digital Oscilloscope Features oscilloscope/arbitrary source/frequency spectrum analysis / counter/multimeter Large 5.7" TFT color LCD display with backlight. USB Host/Device 2.0 full-speed interface with removable disk support. RS-232/LAN optional. Easy to control with PC or at long-distance. Bandwidth 60MHz Functions of high precision digital multimeter(6000 counts). AC/DC voltage AC/DC current Resistance Capacitance Continuity Diode test High refresh rate. High real-time sample rate 250MSa/s, 50GSa/s equivalent-time sample rate. Math: FFT , + , - , * , / ,X-Y. Pass/Fail function. 22 automatic measurements. Multiform trigger mode, 2 separate time base in ALT trigger mode. Easy to see 2 signal with different frequencies. 1000 waveform records. Installed battery: 6 hours work time. Saving waveforms in .jpg/.bmp format, MS excel/word files. LabviewVBVC second design instance. Software compatible with: Windows NT, Windows 2000, Windows XP ,VISTA Hantek DSO8060 can be connected to a PC MATH, REF Multimeter mode ALT MAG, easy to search for signal The cursor function 22 automatic measurements X-Y mode FFT ALT trigger mode, dual time base, easy to observe two signals of different frequency Built-in help system Test signal more than 100MHz by ETS mode Document management, and convenient file storage and management Hantek DSO8060 Handheld Digital Oscilloscope Technical Specifications Vertical Bandwidth 60MHz Sample rate 250MS/s Channels 2 Five-in-one oscilloscope/arbitrary source/frequency spectrum analysis / counter/multimeter Input Impedance Resistance 1M Capacitance 15 pF Input Coupling AC, DC and GND Vertical Resolution 8 bits Maximum Input 300V (DC+AC Peak) Horizontal Equivalent Sampling Rate 50GSa/S Memory Depth 32k at Single Channel, 16k at Dual Channel Time Base Precision ±50ppm Trigger Source CH1, CH2 X-Y Mode X-Axis Input Channel 1 Y-Axis Input Channel 2 Phase Shift Max.3 degree Cursors and Measurement Voltage Measurement Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Vcrms, Preshoot, Overshoot Time Measurement Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle Delay Measurement Delay time from ch1 rising edge to ch2 rising edge, Delay time from ch1 falling edge to ch2 falling edge Cursors Measurement Manual, Track, Auto Measure Modes Multimeter Mode Maximum Resolution 6,000 Counts Testing Modes Ac/DC voltage, AC/DC current, resistance, capacitance, diode test, continuity Maximum Input Voltage AC: 600V, DC: 800V Maximum Input Current AC: 10A, DC: 10A Input Impedance 10 M? General information Waveform Signal Process CH1+/- CH2, CH1xCH2, CH1/CH2, FFT, Invert Storage 15 Waveforms and Setups Display TFT LCD Type 5.7 Inch with LED Backlight Display Display Resolution 240 (Vertical) x 320 (Horizontal) Dots USB USB Host / Device 2.0 Full Speed Supported Optional RS232, LAN Power Source AC 100V ~ 240V, 50Hz ~ 60Hz; DC Input: 8.5VDC, 1500mA, Battery Power New (Installed) 6 Hours (Li-ion Battery) Dimension 245 x 163 x 52 mm Weight 1.2kg Hantek DSO8060 Handheld Digital Oscilloscope Package Content Hantek DSO8060 Digital Oscilloscope Box (1pc.) Carrying bag (1pc.) Disc with software (1pc.) Multimeter test leads (2pcs.) Oscilloscope probes (2pcs.) USB (1pc.) Power adapter (1pc.)

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Hantek
Bandwidth	60MHZ
Model	DS08060
Channels	2
MPN	DSO1060
Sample Rate	200MSa/s - 499MSa/s
Type	Digital
Country/Region of Manufacture	China
