Power Toroidal Transformer For Audio Amp & Cnc 230 Ac 80 90 Dc Supply 115 40 45

US $50.00

  • Edmonds, Washington, United States
  • Jan 29th
Open on mobile:
QR code
This auction is for a TOROIDAL POWER TRANSFORMER these were to be used in the mackie M 1400 Power Amplifier.  Acording to mackie data they put out 80 and 90 volts after rectification (see pict 3). This transformer has a 230V input so if used with 115V the output would be half as much. The transformer seems to have 60-0-60 and 65-0-65 center-tapped secondaries. What the schematic diagram is evidently showing, albeit not too well, is a rectified output of +/-80V and +/-90V (or 160V and 180V peak-to-peak).
Condition Used :
An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes “Removed from working equipment.”
