Praxsym Portable Attenuation Measurement System Pams Rf Shield Tested Working

US $2,499.99

Richmond, Virginia, United States
Apr 30th

Open on mobile:
QR code

Praxsym Portable Attenuation Measurement System PAMS RF Shield Tested Working Mouse over images to see larger version Click to view supersize image Praxsym Portable Attenuation Measurement (PAMS) System Item Description: 1x Praxsym Portable Attenuation Measurement System. The Portable Attenuation Measurement System (PAMS) measures the shielding effectiveness of RF enclosures. Both bar graph and numeric readout display the shielding level (dB). Includes the following: Transmitter Receiver Rechargeable Battery Packs (2 each, one installed per unit,) 9.6 V Battery Chargers (2 each) / AC/DC Adapter 32 ohm (Walkman type) headphone set Antennas (2 each) Transit case PAMS Receiver Specifications Frequency 864-936 MHz Detection Mode(s) CW Measurement Range 0dBm to -120dBm Stability +/- 2.5 ppm Charger AC, 95-250 VAC, 47-63 Hz at power jack DC, 15V +/-1.0V Battery Operation 4 hours operation 90 minutes recharge Controls OFF/VOL, MODE, CAL, FREQ, TUNE, T’HOLD, LOCK, LIGHT Indicators BATTERY LEVEL, SIGNAL LEVEL, THRESHOLD SETTING, MODE, LOCK, CAL STATUS, FREQ, FREQ ADJ Headphone Imped. 32 ohms Weight 5.5 lbs. Size 11.7” H x 5.1”D x 4.9”W PAMS Transmitter Specifications Frequency 864-936 MHz Output Power 1 watt (CW mode) -12 dBm (Broadband mode) Operating Modes CW, Combline (750-1000 MHz), 25 MHz steps Attenuation 0 to 60 dB in 1 dB steps Stability +/-2.5 ppm Charger AC, 95-250 VAC, 47-63 Hz at power jack DC, 15V +/-1.0V Battery Operation 2 hours operation 90 minutes recharge Controls OFF/ON, MODE, ATTEN, FREQ, TUNE, LOCK, LIGHT Indicators BATTERY LEVEL, OUTPUT POWER, MODE, LOCK, ATTEN LEVEL, FREQ Weight 5.5 lbs. Size 11.7” H x 5.1”D x 4.9”W PAMS Overall System Specifications End-to-End: 140 dB Dynamic Range Meas. Accuracy +/- 2 dB (-110 to 0 dBm) Channel Spacing 100kHz Operating Temperature 0C to 40C User Interface Full Alpha-numeric Backlit LCD Display The system User's Manual can be found here. Does Not Include cables, accessories or documents not listed. Condition: Powers on. Displays are clear. Controls appear responsive, modes/frequencies and other indicators change in response to controls. Receiver shows flashing "CAL NOT VALID'. No further testing done. Minor cosmetic scuffs and light sticker residue (see pictures). 14 Day DOA Warranty. Location Id: Frank Bulk Frank Payment: Preferred mode of Payment is PayPal. Cashier’s Check and Personal Check are all accepted modes of Payment, please contact us if these are needed to submit payment. Shipping: Purchases will be shipped via FEDEX or USPS. Please note the EBay Listing shows UPS shipping but FEDEX is our preferred carrier. We guarantee to ship your item within 48 hours (except weekend and public holidays) after payment has cleared. This guarantee does not include items that require freight shipping. Your Tracking number will be sent to you via email once the item has been shipped out. Never accept a damaged package! Instead reject the package and contact us ASAP. International Sales: USPS Express Mail International is our preferred shipping method. All import duties & taxes are responsibility of the buyer. We do offer FedEx Air Freight for items not able to be shipped USPS. International Buyers Interested in Container Quantities - PLEASE contact us through EBay Messaging for more information and pricing. Freight: All Heavy and Bulky items that do not meet the weight and size of regular mail have to be shipped freight. Items shipped by freight are exempt for our 48 hour shipping guarantee. Please contact us for a freight quote Shipping Address: Items can only be shipped to the verified shipping address that is submitted with your PayPal payment. If your PayPal address does not match the shipping address, please modify the address before submitting payment. Please notify us through the EBay Messaging panel. If no notification is received and your item is shipped to the incorrect address you (the buyer) will responsible for any additional charges. Contact: We answer customer emails regularly during our normal business hours (M-F, 7am-4pm Eastern). If you ask a question on a weekend or holiday, we will answer your question promptly on the following business day. Please allow at least 24 hours for a reply. Feedback: We are happy to leave positive feedback as soon as your on-time payment clears, and we appreciate your positive feedback when your transaction is successful. Remember, we are always willing to work with you on any problems you may experience, so please contact us before considering a negative remark. If you are unfamiliar with the feedback system, please check out eBay’s Feedback Policy. General: PLEASE NOTE: If you think an accessory (Adapters, Power Cables, PROBES, and Manuals etc.) should be with this item, and it is not pictured or not mentioned, it is NOT included. Unless otherwise stated all items shown in pictures are actual product being auctioned. A phone number must be provided before we ship so carriers can contact you with any delivery issues. Our items are sold “as described”. We stand 100% behind what is mentioned in our listing. We strive to describe our items as accurately as we can; still if we make a mistake we will make it Right. PLEASE NOTE, THE FDA DISCLAIMER BELOW IS FOR MEDICAL DEVICES/EQUIPMENT REQUIRING GOVERNMENT AUTHORIZATION: "The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, do not bid on this item unless you are an authorized purchaser. If the item is subject to FDA regulation, we will verify your status as an authorized purchaser of this item before shipping of the item." “This unit has been used. It has been cleaned in accordance with the manufacturers guidelines by the medical facility from which we received it.”

“Controls appear responsive, modes/frequencies and other indicators change in response to controls.”

Brand	Praxsym
MPN	PAM
Model	Portable Attenuation Measurement System
