Precision Square Tombstone for 800mm Pallet, US $1500 – Picture 0
Precision Square Tombstone for 800mm Pallet, US $1500 – Picture 0

Precision Square Tombstone For 800mm Pallet

US $1500

  • Cincinnati, Ohio, United States
  • Jun 2nd
Open on mobile:
QR code
FEATURES: Precision four-sided tooling block for machining-center pallets. All four faces are accurately finish ground to tight tolerances, and qualified to the base. All multipurpose holes are spaced within .0008" of true position. One-piece cast construction provides superior accuracy, dimensional stability, and vibration dampening. MOUNTING: Dual mounting capability allows both JIS mounting (locating from two reference edges) and DIN mounting (locating from center and radial holes) with excellent accuracy. Mounting holes fit almost any USA or metric slot spacing.  MATERIAL: Body > Gray cast iron, ASTM class 45. Bushings > High-carbon steel, heat treated. Threaded inserts > Steel. Protection Plugs > Plastic. MODULAR FIXTURING, MODULAR TOOLING PLATES & BLOCKS, Four-Sided Tooling Blocks -- Carr Lane Manufacturing Co-
