Pro-face Color Operator Interface Panel 2880061 Gp2400-tc41-24v (s14-1-200g)

US $1900

Louisville, Colorado, United States
Jan 29th

Open on mobile:
QR code

DESCRIPTION This is a PRO-FACE COLOR OPERATOR INTERFACE PANEL. INCLUDES MOUNTING HARDWARE. MODEL: 2880061 PN: GP2400-TC41-24V Type TFT Color LCD Display Colors 256 colors (no blink)/ 64 colors (3-speed blink) (software control)*1 Backlight CCFL (Service life: more than 50,000 at 24 hr. operation) Resolution 640 x 480 pixels Effective Display Area (mm) 149.8(W) x 112.3(H) Brightness Control 4 levels of adjustment available via touch panel Contrast Control - Language Character Sets ASCII: (Code page 850) Alphanumeric (incl. European characters) Chinese: (GB2312-80 codes) simplified Chinese fonts Japanese: ANK 158, Kanji : 6962 (JIS Standards 1 & 2) Korean: (KSC5601 - 1992 codes) Hangul fonts Taiwanese: (Big 5 codes) traditional Chinese fonts Text 8 x 8 dots 80 char. x 60 rows 8 x 16 dots 80 char.x 30 rows 16 x 16 dots 40 char.x 30 rows 32 x 32 dots 20 char.x 15 rows Character Sizes*2 8 x 8 dots, 8 x 16 dots, 16 x 16 dots, 32 x 32 dots Font Sizes Width can be expanded 1 to 8 times. Height can be expanded 1/2*3, 1 to 8 times. Application Memory FLASH EPROM 4MB Data Backup Memory 256KB SRAM - uses lithium battery*4 Touch Panel Resolution 32 x 24 keys/ screen - 1 or 2 point touch External Interface Serial Interface Asynchronous Transmission methods: RS-232C/RS-422, Data Length 8/7 bits, Stop Bit 2/1 bits, Parity: None, Odd or Even Transmission Speed: 2400bps - 115.2Kbps, 187.5Kbps*5 Expansion Serial Interface RS-232C Asynchronous Transmission Method: RS232C, Data Length: 7 or 8 bits, Stop Bit: 1 or 2 bits, Parity: None, Odd or Even, Data Transmission Speed: 2400 to 38400 bps Network Interface IEEE802.3, 10BASE-T CF Card Interface 1 Slot Sound Output Interface External Speaker Connection (Terminal Block) Monaural 1CH Speaker Output 70mW (Rated Load: 8?, Frequency: 1kHz) Sound Line Out Output 2.7Vp-p (Rated Load: 10k?) Wire Gauge: AWG28 to AWG16 AUX Input/Output Interface Remote Reset Input Remote Reset Input: 1 point, Input Voltage: DC24V ±10%, Input Current: 4mA (TYP), Min. Input Pulse Width: 2ms Operating Voltage: (When ON) Min. DC21.1V/ (When OFF) Max. DC3V Isolation Method: Photocoupler Isolation Output Output: 3 Points (RUN Output: 1 point, System Alarm Output: 1 point, External Buzzer Output: 1 point) Rated Voltage: DC24V, Max. Rated Current: 50mA/ point, Wire Gauge: AWG28 to AWG16 Printer Interface Compatible with NECPC-PR201/PL, EPSON ESC/P24-J84(C), HP Laser Jet, PCL 4 command, EPSON PM/Stylus (6-color ink), EPSON Stylus (4-color ink) compatible printers*6 Tool Connector Asynchronous TTL level nonprocedure command I/F Used for transferring data between the GP application software and the GP. Used for data transfer with the 2-Port feature. Used for a variety of devices, including a bar-code reader. GUARANTEED TO BE IN WORKING ORDER UPON ARRIVAL. PLEASE DISREGARD THE NUMBERS IN PARENTHESES AT THE END OF THE DESCRIPTION IN THE TITLE, THESE ARE FOR OUR INTERNAL REFERENCE. WE OFFER A 14 DAY RIGHT OF RETURN. PAYMENT We accept Paypal. Payment must be made within 3 days of item ending. SHIPPING We take great care in packaging your products and use only the best materials. We usually ship USPS for smaller domestic shipments. For larger items, we use FedEx or UPS. We also ship freight for very large and heavy items. In order to give you the lowest possible rate, we combine shipping charges on multiple orders. WE SPECIALIZE IN INTERNATIONAL SHIPPING. International Shipping rates will be higher than the rate posted here. Please contact us for international rates. TERMS OF SALE All items are guaranteed to be in proper working order upon arrival, unless specified otherwise in the description. ABOUT US We have been in the Industrial and manufacturing supply field for over 7 years and take pride in providing our customers with THE BEST CUSTOMER SERVICE. CONTACT US We do our best to describe everything. If you have questions, please feel free to email us. We strive hard to make sure our customers are happy. We use the appropriate packaging materials that are necessary when packaging your items. We hope that you will find your purchase satisfying. If by chance there is an issue with your item, please let us know right away. We are always ready to address any concern.
