Professional Vector Frequency Inverter 3-phase 380v 1.5kw Svpwm 3ph

US $102.00

  • Shenzhen,Guangdong, China
  • Jan 29th
template Professional Vector frequency  inverter 3-phase 380V 1.5KW SVPWM 3PH input Rated voltage / frequency 3-phase 380V;50Hz/60Hz Change the permissible value Voltage: -20% ~ + 20% voltage unbalance rate: <3% Frequency: ± 25% Output Rated voltage 0~380V Frequency Range 0Hz~500Hz Frequency resolution 0.01Hz Overload 150% of rated current for 1 minute, 180% rated current 3 seconds               The main control functions Modulation Optimization of space vector SVPWM modulation current Control No sense of vector control (with optimal low frequency compensation  characteristics Dead) Frequency accuracy Digital setting: the highest frequency x ± 0 01%; simulation  settings: the highest frequency x ± 0.2% Frequency Resolution Digital setting: 0.01Hz; simulation setting: the highest frequency x  0.1% Starting frequency 0.40Hz~20.00Hz Torque boost Automatic torque boost, manual torque boost of 0.1% to 30.0% V/FFFFF curve Five ways: constant torque V / F curve, one kind of user-defined  multi-segment V / F curve mode and three kinds of reduced torque  characteristic curve method (2.0 times the power, 1.7 times and 1.2  times the power of power) Acceleration and deceleration curves Two ways: linear acceleration and deceleration, S curve acceleration  and deceleration; seven kinds of acceleration and deceleration time,  time units (minutes / seconds) Optional, up 6000 minutes DC braking DC braking start frequency: 0 ~ 15.00Hz Braking time: 0 to 60.0 seconds braking current: 0 ~ 80% Dynamic braking Built-in dynamic braking unit, an external braking resistor Jog Jog Frequency Range: 0.1Hz ~ 50.00Hz, jog ramp time of 0.1 to 60.0  seconds Built-in PI Can easily form a closed loop control system Multi-speed operation Through the built-in PLC or control terminal to achieve multi-speed  operation Traverse Can achieve preset frequency, center frequency adjustable wobble  function Automatic voltage regulation (AVR) When the grid voltage changes, to maintain the output voltage  constant Automatic energy-saving operation Depending on the load, automatically optimize V / F curve,  energy-saving operation Automatic flow limiter During the current automatic limit on the run to prevent frequent  overcurrent fault trip Fixed length control After stopping the inverter reaches the set length Communication function With RS485 standard communication interface, support MODBUS ASCII  and RTU communication protocol in two formats. Has a master-slave  multi-machine interaction function Run function Run the command channel Operation panel given; given control terminal; serial port given;  are three ways to switch Frequency setting channel Keyboard analog potentiometer given; keyboard ?, ? keys given; function code number given;  serial port given; terminal UP / DOWN given; analog voltage  reference; analog current setting; pulse given; combination to set;  given way to a variety of switching at any time Switch the input channel Reverse instruction; 8 programmable digital inputs, can be set 35  kinds of functions. Analog input channels 2 analog inputs, 4 ~ 20mA, 0 ~ 10V optional Analog output channels Analog output, 4 ~ 20mA or 0 ~ 10V optional, enabling output setting  frequency, output frequency and other physical quantities Switching pulse output channel A programmable open collector output; 1 relay output signal; 0 ~  20KHz pulse output signal one way to achieve a variety of physical  output   Operation  Panel LED digital display Can display setting frequency, output voltage, output current and  other parameters External instrument display Output frequency, output current, output voltage display other  physical display Key Lock Achieve full lock keys Parameter Copy Remote control can be achieved using the keyboard function code  parameter copy function between drives Protection Overcurrent protection; overvoltage protection; undervoltage  protection; overheating protection; overload protection, etc Optional parts The brake assembly; remote operation panel; remote cable; keyboard  mounts, etc.     Environment Use spaces Indoors, away from direct sunlight, dust, corrosive gases, oil mist,  water vapor, etc. Hyperion height Lower than 1000 m (higher than 1000 m with derating) Ambient temperature -10°C~+40°C Humidity Less than 90% RH, non-condensing Vibration Less than 5.9 m / s 2 (0.6M) Storage Temperature -20°C~+60°C Structure Protection class IP20 (in the selection of state or keyboard display unit status) Cooling Forced air Installation Wall, cabinet installation What in  Package: 1 x Set of Vector frequency  inverter 3-phase 380V 1.Your valid phone number is  very necessary for the shipping, otherwise we can't guarantee that the package  would safely arrives. 2. Any Customs tax applied to this package should be covered by buyers. Payment 1. Payment methods  accepted : Paypal  only. 2. Payment must be  received within 7  business days of  auction closing.   Shipping 1. We ship your  orders within 1-2  business days after  the payment  received. 2. Item shipped via  Singapore Post or  HongKong Post , It  takes about 7-14  business days (USA,CA,AU,UK).others  country 10-20  business  days(Brzil,India,RU),Exact  delivery time  depends on postal  process. 3. If you do not  receive your item(s)  by 30 business  days,Please feel  free to contact us  via ebay mail system  , we will try our  very best to resolve  any problems with  you    Return Policy 1. Return is  accepted within 14  days after the  buyer's receiving  the item. 2. If this item is  defective upon  receipt, customer  has up to 14 days  from date of receipt  for exchange of a  new one. 3. Unused/unopened  merchandise will be  fully credited.   Other Policies   We are not  responsible for any  custom duty or  import tax.   If you need we write  low price on  shipping bill, pls  leave message when  you make payment .   All emails will be  answered within 24  hours. If you do not  receive our reply,  please kindly  re-sent your email  and we will reply to  you as soon as  possible, Suggest  send eBay message to  us, That is easy to  find .
