PTN78000WAZ POS VOL REG OUTPUT 3.3V to +15V 1.5 A, Wide Input, Through-Hole, US $15.00 – Picture 0
PTN78000WAZ POS VOL REG OUTPUT 3.3V to +15V 1.5 A, Wide Input, Through-Hole, US $15.00 – Picture 0

Ptn78000waz Pos Vol Reg Output 3.3v To +15v 1.5 A, Wide Input, Through-hole

US $15.00

  • Brooklyn, New York, United States
  • Jan 29th
Open on mobile:
QR code
You ARE BUYING  1   PTN78000WAS Through-Hole Module (EUS) , Brand new,  in Anti-static seal PTN78000WAS,  Features 1.5-A Output Current Wide-Input Voltage (7 V to 36 V) / (15 V to 36 V) Wide-Output Voltage Adjust  (2.5V to 12.6 V)  High Efficiency (Up to 95%) On/Off Inhibit Undervoltage Lockout Output Current Limit Overtemperature Shutdown Operating Temperature: -40°C to 85°C Surface Mount Package  APPLICATIONS General-Purpose, Industrial Controls, HVAC Systems, Test and Measurement, Medical Instrumentation, AC/DC Adaptors, Vehicles, Marine, and Avionics Description The PTN78000 is a series of high-efficiency, step-down Integrated Switching Regulators (ISR) Operating from a wide-input voltage range, the PTN78000 provides high-efficiency, step-down voltage conversion for loads of up to 1.5 A. The output voltage is set using a single external resistor. The PTN78000W may be set to any value within the range, 2.5 V to 12.6 V.   The output voltage of the PTN78000W can be as little as 2 V lower than the input, allowing operation down to 7 V, with an output voltage of 5 V, The PTN78000 has undervoltage lockout and an integral on/off inhibit. The modules are suited to a wide variety of general-purpose applications that operate off 12-V, 24-V, or 28-VDC power.
