Raven Scs-750 Console

US $1600

The Dalles, Oregon, United States
Jun 8th

Open on mobile:
QR code

Used Raven SCS-750 Console with wiring harness in good cosmetic and working condition. Control for up to 5 products. The following is an excerpt from the Users manual: The Raven SCS 750 (CHEMICAL INJECTION SPRAY SYSTEM) is designed to improve the accuracy and uniformity of spray applications. Its performance relies on the installation and preventive maintenance of the complete sprayer. It is important that this Installation and Service Manual be reviewed thoroughly before operating the system. This Manual provides a simple step-by-step procedure for installing and operating. The SCS 750 system consists of a computer based Control Console, Speed Sensor, Control Valve, Flow Meter, one to five Injection Modules (each includes a Motor Control and Metering Pump with sensors), Inline Mixer, and cables. The Console mounts directly in the cab of the vehicle for easy operator use. The Radar Speed Sensor is mounted to the frame of the vehicle or implement (Wheel Drive Speed Sensor and Speedometer Drive Speed Sensor are also available). The Injection Module mounts to the framework of the sprayer. The In-line Mixer mounts just before the Boom On/Off Valves. Appropriate cabling is furnished for field installation. The operator sets the target application rate for each chemical to be sprayed and the SCS 750 automatically maintains the flow regardless of vehicle speed or gear selection. A manual override switch allows the operator to manually control flow for each chemical for spot spraying. Actual volume per area being applied is displayed at all times for all chemicals. The SCS 750 additionally functions as an area monitor, speed monitor, and volume totalizer
