REALTEK ALC269 QFN48 Ship from US, US $3.91 – Picture 0

REALTEK ALC269 QFN48 Ship from US, US $3.91 – Picture 1

REALTEK ALC269 QFN48 Ship from US, US $3.91 – Picture 2

Realtek Alc269 Qfn48 Ship From Us

US $3.91

Tucson, Arizona, United States
Jan 29th

Open on mobile:
QR code

Our mission is to give you the e–components you need without having to deal with long delivery times from China. All of our components are already in the US. You can order 1pcs of any part, there is no minimum for ordering. just place an order and you will have your parts in no time! All components come in brand new condition with a 2 months limited warranty, you have plenty of time replace them if needed. High Definition Audio Codec with Embedded Class D Speaker Amplifier General Description The ALC269 is a High Definition Audio Codec that integrates a 2+2-channel DAC, a 4-channel ADC, and a Class D Speaker Amplifier. The 2+2-channel DAC supports two independent stereo sound outputs simultaneously. The 4-channel ADC integrates two stereo and independent analog sound inputs (multiple streaming). The ALC269 incorporates Realtek converter technology to achieve a 98dB dynamic range playback quality and a 98dB dynamic range recording quality. It meets the current WLP3.10 (Windows Logo Program) and future WLP requirements that become effective from 01 June 2008. The ALC269 also supports stereo digital microphone channels (microphone array) with Acoustic Echo Cancellation (AEC), Beam Forming (BF), and Noise Suppression (NS) technology simultaneously, significantly improving voice quality for PC VoIP applications. As well as basic audio functions, the ALC269 has two independent SPDIF outputs; one could be used to connect a PC to high-quality consumer electronic products such as digital decoders and speakers, the other could provide a dedicated digital output to a HDMI transmitter (common in high end PCs). There are three integrated power amplifiers. The first is a linear headphone amplifier at port C. The second headphone amplifier at port A removes the need for external DC blocking capacitors, eliminating pop noise caused by these capacitors. The third is an integrated stereo Class D amplifier to directly drive a mini-speaker. The Class D amplifier is designed to drive speakers with as low as 4? impedance. Its maximum output power is 2.3W per channel at 5V power supply. The advantage of an integrated Class D amplifier in the ALC269 is high efficiency with low power consumption. The ALC269 integrates five hardware equalizer bands composed of one low-pass filter, one high-pass filter, and three band-pass filters to compensate for mini-speaker frequency response. All the equalizer filters are programmable via the BIOS, allowing the equalizer to function without the need to customize the audio driver. The ALC269 conforms to Intel's Audio Codec low power state white paper and is ECR compliant. Features Hardware Features98dB Signal-to-Noise Ratio (A-weighting) for DAC output 98dB Signal-to-Noise Ration (A-weighting) for ADC input Meets WLP (Windows Logo Program) 3.10 and future WLP requirements that become effective from 01 June 2008 2+2-channel DAC supports 16/20/24-bit PCM format for independent two stereo channel audio playback 4-channel ADC supports 16/20/24-bit PCM format for independent two stereo channel audio inputs All DACs supports 44.1/48/96/192kHz sample rate All ADCs support 44.1/48/96kHz sample rate SPDIF-OUT support 16/20/24-bit format and 32/44.1/48/88.2/96/192kHz rate Supports MONO line level output Supports external PCBEEP input and built-in digital BEEP generator Software selectable 2.5V/3.2V/4.2V VREFOUT as bias voltage for analog microphone input Two jack detection pins each designed to detect up to 4 jacks 1dB resolution of input and output volume control Programmable +10/+20/+30dB boost gain for analog microphone input Built-in headphone amplifiers for port-A and port-C. 2 GPIOs are supported for customized applications (pin shared with digital microphone interface) EAPD (External Amplifier Power Down) is supported (pin shared with secondary SPDIF-OUT) Supports Anti-pop mode when analog power AVDD is on and digital power is off Power support: 3.3V digital core power; 1.5V~3.3V digital IO power for HDA link; 3.3V~5.0V analog power; 3.3V~5.0V power stage voltage Enhanced power management features Secondary SPDIF-OUT supports 16/20/24-bit format and 32k/44.1k/48k/88.2k/96k/192kHz rate Supports stereo digital microphone input Programmable boost gain and volume control for digital microphone input Headphone amplifier for port-A does not require DC blocking capacitors Stereo Bridge-Tied Load Class-D amplifier at port-D has 2Watt (rms)/4? per channel output Short circuit and thermal overload protection for Class D amplifier Supports digital PWM output at port-D which system integrator can easily connect the output to external power amplifier receives digital audio stream Five band hardware equalizer designed for BTL output (port-D) to compensate for frequency response while driving the mini-speaker Intel low power ECR compliant: supports power status control, jack detection, and wake-up event in D3 mode 48-pin QFN ‘Green’ package Software Features Compatible with Windows Logo Program 3.10 and future requirements that become effective from 01 June 2008 WaveRT-based audio function driver for Windows Vista EAX™ 1.0 & 2.0 compatible Direct Sound 3D™ compatible A3D™ compatible I3DL2 compatible HRTF 3D Positional Audio (Windows XP only) Emulation of 26 sound environments to enhance gaming experience Multi-band software equalizer and tools Voice Cancellation and Key Shifting in Karaoke mode Dynamic range control (expander, compressor, and limiter) with adjustable parameters Intuitive Configuration Panel (Realtek Audio Manager) to enhance user experience Provides 10-foot GUI for Windows Media Center Microphone Acoustic Echo Cancellation (AEC), Noise Suppression (NS), and Beam Forming (BF) technology for voice application Smart multiple streaming operation HDMI audio driver for AMD platform Dolby® PCEE program™ (optional software feature) SRS® TrueSurround HD (optional software feature) Fortemedia® SAM™ technology for voice processing (Beam Forming and Acoustic Echo Cancellation) (optional software feature) Applications Windows Vista premium desktop and laptop PCs Information appliances (IA) with High Definition Audio Controller Feedback: Once you have received your item, please leave feedback for us as this will inform us that you have received your items. · Please leave us a positive feedback after you receive your order, we will give you a positive feedback soon. · Your satisfaction is most important for us. If you have a problem or question regarding your transaction, please contact us before leaving any type of feedback. And give us the opportunity to reasonably rectify in a reasonable amount of time, whatever your concern may be. Negative feedback does not solve anything. We are always willing to work things out. If we don’t know about it, we can’t fix it. So feel free to contact us. Thank you very much!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Realtek
MPN	ALC269
Model	ALC269 QFN48
