Recepticle Connector M28840/12bg1f1

US $160

Hurricane, Utah, United States
Jun 14th

Open on mobile:
QR code

Recepticle Connector M28840/12BG1F1 CONNECTOR,RECEPTACLE,ELECTRICAL MFG P/N: M28840/12BG1F1 NSN: 5935-01-283-9592 FSC: 5935 - Connectors, Electrical MFG: Military Standards Description: CONNECTOR,RECEPTACLE,ELECTRICAL INVENTORY IS AVAILABLE. ACT NOW! SUBMIT A QUICK QUOTE. Technical Characteristics ~1 data on certain environmental and performanc Precious Material And Weight 0.092 gold grains, troy Included Contact Type round pin single mating end single contact grouping Insert Position In Deg 160.0 and 191.0 and 116.0 and 311.0 Shell Surface Treatment Document And Classification qq-p-416,ty 2,class 3 fed spec all treatment responses Criticality Code Justification feat Mating End Quantity 1 Precious Material gold Unthreaded Mounting Hole Diameter 0.142 inches minimum and 0.157 inches maximum Polarization Method keyway or multiple keyway Center To Center Distance Between Mounting Facilities Parallel To Height 1.392 inches nominal Nominal Thread Length 0.450 inches Contact Material copper alloy single mating end single contact grouping Thread Quantity Per Inch 10 Distance From Mounting Shoulder To Front Face 0.878 inches minimum and 0.898 inches maximum Overall Width 1.798 inches minimum and 1.838 inches maximum Included Contact Quantity 92 single mating end single contact grouping Thread Direction right-hand Thread Series Designator double stub Special Features 20-20 wire size pin contacts in lieu of 20-22 Connector Locking Method externally threaded shell Specification/standard Data 81349-mil-c-28840/12 government specification Overall Length 1.625 inches maximum Environmental Protection thermal shock resistant and heat resistant and corrosion resistant and vibration resistant and moisture resistant and cold resistant Contact Surface Treatment Document And Classification mil-g-45204 mil spec single treatment response single mating end single contact grouping Overall Height 1.798 inches minimum and 1.838 inches maximum Body Style straight shape, external coupling Contact Removability removable single mating end single contact grouping Nominal Thread Size 1.625 inches Precious Material And Location contact surfaces gold Shell Surface Treatment cadmium and chromate Terminal Location back single mating end single contact grouping Test Data Document 81349-mil-c-28840 specification (includes engineering type bulletins, brochures,etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type Shell Type solid Contact Surface Treatment gold single mating end single contact grouping Thread Class 2a Insert Material plastic fluorosilicone single mating end Distance Between Centerlines Of Mounting Facilities Parallel To Body Width 1.392 inches nominal Threaded Device Type coupling facility Terminal Type crimp single mating end single contact grouping Shell Material steel Subject to prior sale! Photos show everything that is included. For more information, or to contact us, please feel free to visit our ME page. 30 day Right of Return if not satisfied. Thanks for looking!!! Please visit our store for more great items! 7630 - S-6 BX 25
