Regulator With Digital Display Step-down Power Module Modules Lm2596s

US $7.17

  • shanghai, China
  • Aug 20th
Open on mobile:
QR code
Type:Step-Down Module Package includes:1pc module With LED Voltmeter Display Color:Green Board Model:LM2596S Features: With power indicator With voltmeter display, using advanced microprocessor, voltmeter error ± 0.05V, range 0 ~ 40V. (Note: To ensure the accuracy of the voltmeter, please ensure that the input voltage is above 4V) Tap the right button to switch the measurement input or output voltage, and the indicator light shows which voltage is being measured, and save the settings, even if it is powered off and then on. The voltmeter can be turned off, and it can be easily realized by tapping the left button when it is not needed. With terminal block, no soldering iron can be used conveniently, and retain the wire bond point The input voltage is 4.0~40V (the input voltage must be 1.5v higher than the output voltage.) Adjustable output voltage range from 1.25V to 37V continuously adjustable (input voltage must be 1.5V higher than output voltage) Maximum output current can be as high as 3A, normal stable working current is 2A Using 150KHz internal oscillation frequency, it belongs to the second generation of switching voltage regulator, with low power consumption and high efficiency. With overheat protection and short circuit protection
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Country/Region of Manufacture China
MPN Does Not Apply
Output Voltage Range 1.25V to 37V
Brand Unbranded
Input Voltage Range 4.0~40V
Manufacturer Part Number Does not apply
Conversion Direction Step-Down
Label ATMA2B12/1135
Current Conversion DC to DC
UPC 772921188043
