Rei Osc-5000e Omni Spectral Correlator

US $8,000.00

Ichihara, Chiba Japan, Japan
Feb 22nd

Open on mobile:
QR code

REI OSC-5000E Omni Spectral Correlator RF System: •RF Receiver Type: Quad Conversion Super Heterodyne with 3 phase locked loop synthesizers •RF Frequency Coverage: 10kHz-3GHz •Tuning Resolution: 100Hz •Sensitivity: 0.8µV typical with 15kHz Bandwidth (+15dBm MAX) •Demodulators: AM, FM Wide, FM Narrow. FM SC, SSB/CW •IF Bandwidth: 250kHz, 15kHz, 6kHz •Attenuators: 0, -20dB at active whip, Discone, and VLF-MF input •Dynamic Range: 90dB •Subcarrier Tuning Range: 15kHz-250kHz •Antenna Types: Balanced Loop 10kHz-500kHz (35-45kHz Narrow) •Active Whip: 500kHz-1500MHz •Discone: 1500MHz-3000MHz •Infrared Detector: 10kHz-5MHz, 850-1070nM •AC Carrier Current: 10kHz-5MHz (Balanced Across Power Line) Control System: •8/16 Bit Microcontroller •512K Static RAM Memory •Optical Encoder: 128 Pulse/Rev with variable count ratio •Program Key: 256K Byte ROM •Display: 128 x 256 Segment Graphics Supertwist LCD •Printer: 192 Dot Per Line Graphics on 2" wide thermal paper Audio System: •Frequency Response: 50Hz-15kHz •Voiceband Filter: 300Hz-3000Hz -18dB/Octave •AGC Dynamic Range: 60dB •Output Power: 3W @ 4 •Headphone Output: 0-2V rms @ 220 •Record Output: 50mV rms (with AGC) @ 500 •Remote contact: Normally Open (200mA 32V MAX) •Balanced Auxiliary Input: 0.5V rms Nominal @ 600 •Reference Audio Input: 1mV - 1V rms @ 3.9K •Sonic Correlator: 50Hz - 15kHz (Frequency Independent) •Audio Alarm: 3 Level Programmable Two Tone Ringer •Squelch: Automatic digital or manual control over full display range •Headphones: Low acoustic leakage, output limited to 105dBA Power System: •AC Input: 105-130/210-260VAC, 50-60Hz, 24W •External DC Input: 12-l8VDC, 1A max •Internal Battery: 12.6V, 2.9 Ah 3 hour operation per charge typical Mechanical: •Size(HxWxD): 6.25 x 18.5 x 14.5 in (47 x 36.8 x 15.9 cm) •Weight: 11 kg Accesories: Audio Patch Cord4ft and Miniature Microphone,OSCOR Video Patch Cord, OSCOR Audio Recorder and Cables,Video Monitor,12VDC Car Adapter,VLF Adapter, Balaced Audio Coupler,Locator Probe,Modulator Phone Adapter,Low Leakage Headphone, Miniplug Extension Cable12ft(3.66m),RF Extension Cable 12ft,Triangulate and Locate,AC PowerAdapter,Modular Telephone Cable

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Brand	REI
Model	OSC-5000E
