Rf Wifi Wlan 802.11 Outdoor Marine Band Pass Ip67 Filter 2400-2484 Mhz Data New

US $390

Sunnyvale, California, United States
Jun 18th

Open on mobile:
QR code

Present your best items with Auctiva's FREE Scrolling Gallery. All items in Telenochek RF store are categorized with extensive detailed categories to simplify searching through the items. Be sure to take advantage of the categories! For sale is: RF, microwave band pass filter in 'new old stock' condition, tested with VNA data. Please see pictures and data table. *We test every item before shipment* Additionally, 90% of filters in this specific listing come with original test spec sheet. This is a full band 2400 - 2484 MHz outdoor 802.11 WiFi / WLAN / ISM / unlicensed spectrum 2.4 GHz filter. The design is 8 pole cavity. This filter is rugged and IP67 rated. There is a thick layer of corrosion resistant paint, it is likely that the filter is salt fog ASTM G85 A2 rated or can be easily painted on top of existing paint. Built by Trilithic - a well-known high quality RF microwave company. Supports 802.11b, 802.11g and the 2.4GHz portion of 802.11n. 802.11n adds MIMO - essential for high performance / high reliability links, as MIMO significantly mitigates multipath fading. The filter is fixed and cannot be retuned to a different center frequency due to layers of anti-corrosive paint. ***Note on lightning protection: a number of cavity filters offered in the general marketplace (including this one) are DC / LF shorted, which offers a low impedance path between center and outer conductors for low frequency signals such as lightning (spectral content up to 2 MHz) . This path does NOT constitute "full lighting protection" by itself. Full lightning protection involves proper grounding of the entire lighting protection element, including outer conductor and consideration of full ground path.We recommend using a lightning arrestor from Times Microwave or Huber Suhner, properly grounded to a metallic superstructure such as metallic mounting pole, mast, or grounded building entry panel. Type WiFi WLAN BPF, 8 pole filter Manufacturer Trilithic Inc Seller SKU TMRF_3V17 Outdoor, IP rating Indoor / Outdoor / IP67 rated. N connectors with gasket. Corrosion Resistant Possibly ASTM G85 A1 and A2 (salt fog) rated, anti-corrosive paint. Lightning protection DC / low frequency shorted to ground. See *** note above Operating Temperature will be tested by seller with VNA and temp chamber (TBD), minimum -10 to +60C, but need to test for this specific model Non-operating / storage Temperature -54 to +125C Vibration and Shock 5 G's Port 1 N(f) Port 2 N(f) Pass Band Specifications: Pass Band 2400-2484 MHz Insertion Loss (dB) -0.50 Return Loss / VSWR better than -18dB / 1.30 VSWR WiFi Channels: 20 MHz: CH1 - CH13, 40 MHz: CH3 - CH11 Center Frequency (MHz) 2442 1dB Pass Bandwidth (MHz) 84.0 1dB Pass Low (MHz) 2400 1dB Pass High (MHz) 2484 Rejection Specifications: DC - 2293.5 MHz 65 dB min 2293.5 - 2352.5 MHz 33 dB min, measured up to 50 dB 2500 - 2589.5 MHz 22 dB min 2589.5 - 2700 MHz 65 dB min Power handling ( Watt CW) 50 Watt CW minimum For high power testing - we can provide s-parameter sweeps before and after applying high RF power (currently up to 200 Watt RF CW depending on frequency). Please inquire if interested in high power. Shipping: We always pack with care to ensure your item arrives safely in original condition. To lower your shipping costs, we can combine shipping for items purchased within several days. International shipping: We ship internationally. An international shipping estimate calculated by eBay is only an estimate. International customers please contact the seller for shipping price before bidding or purchasing. Buyer is responsible for all extra fees associated with international shipping, such as import and customs duties. Return policy: We work with our customers to resolve any issues they might have. Majority of our items have been professionally tested. Any known problems with components, equipment etc... will be noted in the item description. Do you see an error in the listing? We try our best to provide accurate information and technical measurements. However, sometimes errors happen in the technical descriptions, pictures or data. Please let us know if you notice any discrepancies. Thanks! Thank you for your interest! Questions are invited! Please check out our store for similar items Additional search keywords: band pass filter, BPF , bandpass filter, RF, microwave, MHz, GHz, broadband , wideband, megahertz, gigahertz, 802.11b, 802.11g, 802.11n ISM 2.4GHz, industrial grade revision: 1.5 inventory: PWR3_cat Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
