Rigol Dp811 200 W Dual Range Single Output Power Supply

US $250

Jonestown, Pennsylvania, United States
Jun 6th

Open on mobile:
QR code

Sign up for our newsletter Rigol DP811 200 W Dual Range Single Output Power Supply Part Number: RIGOLDP811 Manufacturer's Description Power Supply with a 200 W single output, 10 mV/10 mA measurement resolution Need Help With Your Purchase? We would love to help. Speak with an agent today! Description Single Output, Dual Range 200 W Power Supply SCPI Status Registers All the SCPI instruments execute the status register operations in the same way. The status system records the various instrument states into three register sets: status byte register, standard event register and questionable status register sets. The status byte register records the advanced summary information reported by other register sets. The SCPI status systems of the DP800 series multi-channel models. SCPI Command Overview SCPI (Standard Commands for Programmable Instruments) is a standardized instrument programming language that is built upon the standard IEEE488.1 and IEEE 488.2 and conforms to various standards (such as the floating point operation rules in IEEE754 standard, ISO646 7-bit coded character for information interchange (equivalent to ASCII programming)). This section introduces the syntax, symbols, parameters and abbreviation rules of the SCPI commands. Build Remote Communication You can build the remote communication between DP800 and PC over USB, LAN, RS232 or GPIB (option, can be extended via the USB-GPIB interface converter) interface. Remote Controls Methods User-defined Programming You can program and control the instrument using the SCPI (Standard Commands for Programmable Instruments) Send SCPI Commands via the PC Software You can control the power supply remotely by sending SCPI commands via the PC software (Ultra Sigma) provided by RIGOL.. OVERVIEW The DP800 Series Power Supplies combine the ability to source, analyze, and coordinate over time in a powerful new package. The DP800 Series is a family of linear power supplies systems with 3 outputs and up to 195 Watts in total. With one channel isolated users can reconfigure instruments into any number of systems or applications. Built in V, A, and W measurements make power monitoring easy, but additional wave tracking, timing, and analysis features means there are even more ways to use the supplies. New digital triggering between instruments also makes it possible to reliably combine and connect supplies together. Intuitive to use for everything from education labs to the R & D bench, the DP800 family of power supplies provide incredible value for any application. Typical Applications R&D Iab General purpose testing Quality Assessment inspection Bias power for RF/MW circuits Automotive electronic test Production testing Device or circuit characterization and troubleshooting Intuitive User Interface DP811 GUI All important data such as voltage, current, power, and limit values can easily be displayed on the display with a diagonal size of 8.9 cm (3.5") and a resolution of 320x240 pixels. LAN Setup Control of the device can be integrated in your own applications, or by using LabView via these interfaces. Output Delay Timing Output Programmable Timer The voltage and current settings can be changed automatically with a timer control. Up to 100 settings can be stored for this purpose, and then activated one after another for variable intervals (specified in seconds). V/A/W Display Changes in the measurement values and settings can be presented very well and in real time using the integrated signal curve display. This makes it possible to detect things like current draw peaks, for example when the current limit is adjusted. Output Analysis Function The analyzer can analyze the file recorded and provides the analysis results, including the number of groups, median, mode as well as the average, VAR, range, minimum, maximum and mean deviation of the voltage, current or power of different channel. Monitor Setup The monitor can monitor the current output state of the instrument. When the user-defined monitor condition is met, the instrument executes the corresponding operation according to the setting in "Stop Mode", like showing a warning, shut off the output or produce a beep sound. Trigger In/Out The rear panel of DP800A provides a digital I/O interface (as shown below) which supports trigger input and trigger output. The 4 data lines are mutually independent and can be used as trigger input line or trigger output line separately. We offer the full manufacturer warranty on most products. Please contact us if you have any questions! About Tequipment.NET Tequipment.NET is one of three divisions of InterWorld Highway, LLC, a well established, authorized manufacturer / distributor of major brands of test equipment. TEquipment.NET provides electrical testing equipment and products for a wide range of electrical applications. We offer an exceptional price match guarantee on qualifying electrical test and measurement tools. In addition, qualifying electric test product orders are shipped free!
