Rigol M3tb24 Instrument Options - 24 Channel Mux Terminal Box

US $3500

Jonestown, Pennsylvania, United States
Jun 23rd

Open on mobile:
QR code

Sign up for our newsletter Rigol M3TB24 Instrument Options - 24 channel MUX Terminal Box Part Number: RIGOLM3TB24 Manufacturer's Description 24 channel MUX Terminal Box Need Help With Your Purchase? We would love to help. Speak with an agent today! Description Rigol M3TB24 24 channel MUX Terminal Box Terminal block for MC3324. Terminal block accessory for M300 DAQ system modules with model numbers ending in 24. Measurement Connections Using External Terminal Blocks M300 provides 6 kinds of terminal blocks to easily connect the signal to be measured to the module. The models of the terminal blocks and corresponding modules are listed in the table below. This section introduces how to use the external block. Terminal Block Module 1 M3TB32 MC3132, MC3232 2 M3TB64 MC3164, MC3264 3 M3TB24 MC3324 4 M3TB48 MC3648 5 M3TB16 MC3416 6 M3TB34 MC3534 Note: for the MC3724, the signal can be connected to the SMB connectors on the module directly. No terminal block is needed. WARNING: Cut off all the power supplies before opening the terminal block or removing the terminal block from the module. 1. Place the terminal block with the front (with the RIGOL caption) facing downward and pull the two latches in the arrow direction in the figure below and press them down. Place the terminal block with the front facing upward and pull the upper cover of the terminal block upward and remove it. 2. Connect the cables for connecting the signal under test according to the labels on the circuit board of the terminal block (for the connecting method, refer to Table 1-1). Pass the binding wires through the two groups of holes as pointed out by the arrows in the figure below to fix the cable connected. Pay attention to the channel or terminal connected to the cable to ensure that the signal connected is correct. 3. Connect the terminal block to the module via interface 1 (the interface definition is in Figure 1-7) on the module and screw down the two screw rods onto the nuts on the module. 4. Close the upper cover of the terminal block. 5. Insert the module with the terminal block into the slot of the mainframe. We offer the full manufacturer warranty on most products. Please contact us if you have any questions! About Tequipment.NET Tequipment.NET is one of three divisions of InterWorld Highway, LLC, a well established, authorized manufacturer / distributor of major brands of test equipment. TEquipment.NET provides electrical testing equipment and products for a wide range of electrical applications. We offer an exceptional price match guarantee on qualifying electrical test and measurement tools. In addition, qualifying electric test product orders are shipped free!
