Ross Ldm-4 Ss Vacuum Planetary Mixer Hv Blades Jacketed

US $44,000.00

Anaheim, California, United States
Jun 9th

Open on mobile:
QR code

Ross Factory Reconditioned LDM-4 Double Planetary Mixer SN# 45793-1 Capacities Mixing Range: 1 quart to 4 gallons (15 liters) Maximum Working Capacity: 4 gallons (15 liters) Full Capacity (mix can) 5.25 gallons (20 liters) General Features Air/Oil Hydraulic Lift with two-hand operation raise/lower air powered controls (80-100 psig air supply required, not included) Designed for vacuum operation up to 29.5"Hg (vacuum pump not included) Change Can design to allow the use of multiple mix cans Stainless Steel type 304 wetted parts polished to an 80 grit finish All non-stainless steel exterior pars painted with a two-part coating All elastomers are Viton Limit Switches to prevent operation of drives when stirrers are in the raised position or when mix can is removed Agitators and Drives Heavy-Duty Stainless Steel type 304 fabricated Gearbox with special gearing and an 80 grit finish New Heavy-Duty High Viscosity "HV" Blades polished to an 80 grit finish Variable Frequency Drive design with 1.5 HP TEFC inverter duty motor for an orbital speed range of 2 to 80 rpm and stirrer blades on their own axis between 4 and 80 rpm Vacuum Hood Stainless Steel type 304 construction Designed for vacuum operation to 29.5"Hg Interior and exterior polished to an 80 grit finish Two (2) 3" diameter combination sight and charge ports Half coupling for vacuum exhaust Mix Can (New) Designed for vacuum operation to 29.5"Hg Designed for use with Ross Discharge Press (not included) Stainless steel type 304 construction Interior and exterior polished to an 80 grit finish 15 psig stainless steel jacket for use with heating/cooling Two (2) stainless steel handles Casters with brakes (two swivel and two rigid) Mixer Bench Carbon Steel Bench includes lower shelf, is painted with Ross off-white two-part epoxy coating, and is supplied with new zinc-pated leveling mounts Control Panel NEMA 12 Enclosure One (1) 1.5 HP VFD internally mounted and designed for 230V, 3-Phase, 60 Hz input Start/Stop Control Emergency Stop Fused rotary disconnect Control Panel is mounted and wired to mixer Instruction Manual included Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

“Many new parts including S/S Bowl and S/S HV Blades”

Brand	Ross Mixing
Country/Region of Manufacture	United States
Model	LDM-4
