Rpj 2n2945a Transistor Gp Bjt Pnp 20v 0.1a 3-pin To-46 Old Gold (1pc)

US $14.95

Stanton, California, United States
Aug 16th

Open on mobile:
QR code

RPJ 2N2945A TRANSISTOR GP BJT PNP 20V 0.1A 3-Pin TO-46 OLD GOLD (1PC) NEW OLD STOCK LOT 32066 F27 Characteristic Specifications SEMICONDUCTOR MATERIAL SILICON INTERNAL CONFIGURATION JUNCTION CONTACT INTERNAL JUNCTION CONFIGURATION PNP VOLTAGE RATING IN VOLTS PER CHARACTERISTIC 25.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-BASE, EMITTER OPEN AND 20.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-EMITTER, BASE OPEN AND 25.0 MAXIMUM BREAKDOWN VOLTAGE, EMITTER-TO-BASE, COLLECTOR OPEN CURRENT RATING PER CHARACTERISTIC 100.00 MILLIAMPERES MAXIMUM COLLECTOR CURRENT, DC POWER RATING PER CHARACTERISTIC 400.0 MILLIWATTS MAXIMUM COLLECTOR POWER DISSIPATION MAXIMUM OPERATING TEMP PER MEASUREMENT POINT 200.0 DEG CELSIUS JUNCTION INCLOSURE MATERIAL METAL MOUNTING METHOD TERMINAL TERMINAL LENGTH 0.500 INCHES MINIMUM TERMINAL CIRCLE DIAMETER 0.100 INCHES NOMINAL TERMINAL TYPE AND QUANTITY 3 UNINSULATED WIRE LEAD OVERALL LENGTH 0.085 INCHES MAXIMUM OVERALL DIAMETER 0.230 INCHES MAXIMUM FEATURES PROVIDED HERMETICALLY SEALED CASE (NON-CORE DATA) SPECIFICATION/STANDARD DATA 80131-RELEASE4490 PROFESSIONAL/INDUSTRIAL ASSOCIATION SPECIFICATION

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Maximum Collector-Emitter Saturation Voltage	-0.1 V
Series	2N2945A
Collector-Emitter Voltage	-20 V, 20 V
Type	PNP BJT
Maximum Base-Emitter Voltage	-3 V
Maximum DC Collector Current	20 A
Mounting Style	Through-Hole
MPN	2N2945A
Maximum Base-Emitter Saturation Voltage	-2 V
Brand	RPJ
Number of Pins	3
Package/Case	TO-46
