Ry-f600 Fusion Splicer W/optical Fiber Cleaver Automatic Focus Function

US $1,615.00

hangzhou,zhejiang, China
Jan 29th

Open on mobile:
QR code

RY-F600 Fusion Splicer w/Optical Fiber Cleaver Automatic Focus Function Introduction: Features: Digital fusion splicer with automatic focus function Fiber core can be display clearly Single X or Y view and X & Y view simultaneously Auto detect cleaved endface fault Display fiber cleaved and offset angle Display core and clad offset 5.1 inch TFT color LCD monitor with clear digital image display USB & VGA interface Software upgrade via USB interface. Specification: Model RY-F600 Applicable fibers SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZDS (ITU-T G.655) Fiber cleaved length 10 ~16mm (Coating diameter<250µm);16mm(Coating diameter250~1000µm) Fiber diameter Cladding diameter:80 ~150µm , Coating diameter:100 ~1000µm Auto focusing Available Fiber aligning method Core aligning, clad aligning, manual aligning Average splice loss 0.02dB (SM), 0.01dB (MM), 0.04dB (DS), 0.04dB( NZDS) Splicing time Typical 9 sec,with standard SM fiber Heating time Typical 36 sec Applicable sleeves 60mm, 40mm and a series of micro sleeves Tension test 2N(option) Electrode life 5000 Battery capacity Typical 400 cycles (splice and heat) Monitor 5.1 inch TFT color monitor Terminal USB 1.1 and VGA , software upgrade via USB interface Operating condition 0 ~ 5000m above sea level, 0 ~ 95%RH and -10~50oCC, respectively, Max. wind velocity of 15m/s Splicing mode Auto ,normal Fiber cleaved angle threshold set 0.1 ~ 10.0 oC , 0.1oCstep Power supply Li-battery 11.8V , AC100-240V DC12.6V/5.0A Dimension L169*W152*H155mm weight 2.4kg 2.9kg(battery) If you need RY-F600P, please conact us by ebay message. Notice: battery not included. Because, the international air shipping forbid to ship liquid, powder and batteries, we can not put them in the package box. Hope you can understand buy them in your local store or supermarket. Hope you can understand and accept! Payment We only accept payment by Paypal. It is the buyer's responsibility if with any duties or taxes. Shipment Carrier Name Estimated Delivery Time Tracking Service China Post Air Mail United Kingdom/France/Canada:15-30 Business Days Australia/Spain/Italy:25-35 Business Days Other:25-50 Business Days It may take longer during the holiday seasons. Issue a Fully Refund if the item doesn't arrive after 60 working days intmail.183.com.cn/icc-itemtraceen.jsp EMS 6-20 Business Days ems.com.cn DHL 3-8 Business Days dhl.com FedEx 3-8 Business Days fedex.com TNT 4-10 Business Days tnt.com ePacket China Only ship to USA, 7-15 Business Days usps.com/ 1. All items will be arranged shipping within handing time after receiving cleared payment. 2. Please check out your detailed address and phone number carefully before submit your order. 3. Any import fees and charges are the buyer responsibility,To ensure your minimum tax,we can declare it as "Gift/Sample" with low value. Return and warranty Warranty is offered for this product.If the product malfunctioned under proper usage per instructions manual within the warranty period,please contact us to obtain shipping instructions and send it back at your shipping costs. 14 days evaluation and investigation takes placed after receiving your return item.A brand new replacement unit will be sent to you at our shipping costs if it meets our warranty requirements. Feedback Your satisfaction is our goal,please leave 5 star feedback .Much appreciation in advance.Please contact us before leave Neutral feedback or Negative feedback,we'll help you to solve all the problems.Otherwise we will not provide technical support,or other solutions.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	RY-F600
Country/Region of Manufacture	China
