Sachets Filling & Sealing Machine For Liquid.

US $5,200.00

FARIDABAD SECTOR 22, HARYANA, India
Jan 30th

Open on mobile:
QR code

AUTOMATIC VERTICAL FORM FILL AND SEAL MACHINE WITH PISTON FILLING PUMP (LIQUID & PASTE). MODEL NO. GE-70M (GMP MODEL) TECHNICAL SPECIFICATIONS Product application Paste, Tomato Ketchup, grease, food paste, cream, gel & liquid syrup etc. Filling Range 50ml & 100ml. Sealing Type Three sided seal. Roll width To be conveyed in mm. Pouch dimensions To be conveyed in mm. Feeding System Volumetric Piston filling pump (Valve body type). Hoper Jacketed hopper with liquid heaters (for maintaining temperature of grease). Heating Controller Electronics type. Filling Pump SS- 304 (AISI) grade make. Contact parts SS- 304 (AISI) Grade. Cladding SS- 304 Speed Approx.30- 35 Pouches per minute (Depends on nature of the product) Main Motor 1/2 Hp, 220 V, 50 Hz, Single Phase, Crompton / GE Make Machine main body Casting (cast Iron). Heater Load 150 W x 2 Nos Laminate Any continuous heat sealable laminate in roll form. Temperature Controller Digital (Radix make). Photocell eye-mark Dual color. Photocell registration system Digital. Pouch counter Yes. Electrical components Schneider make. All electrical wiring Fenolex make. Power Consumption 1.5 Kw Net Weight 350 Kgs (Approx.) Caster wheels PU. Tool Kit Yes. Additional spare parts (Free of cost) Long heaters- 04 pcs. Round heaters- 04 pcs. Optional Attachment (Including with machine) Electronic Batch coding unit device. Salient features GE-70M · Mechanical Automatic Vertical Form Fill Seal Machine. · Cast iron used to construct the machine body. · Continuous rotating sealing jaws used for horizontal sealing. · Continuous rotating die rollers for vertical sealing. · Die rollers used for packing film pulling. · Castor wheels provided for easy location / displacement of machine. Electronic & Electrical Equipments: · Photo eye used will be of standard make. · Analog Thermocouple based Temperature Controller. Filling System: · Volumetric piston filling pump (Valve body type). Photo cell registration system: Pouch length auto correction. · Pouch length auto correction through photo Length / Pitch gear. · Photo cell registration panel. · Reverse / forward motor. Main drive: Motor for main drive (Crompton / GE make). We have considered following key points while proposing you these machines: 1) Economical: Power consumption, Space occupancy will be less. Simple and Easy to operate. 2) Compatible and Proven Similar Product Application: Successfully running for similar product application 3) Accurate and Aesthetic pouch Cutting: This machine is equipped with photo registration control system to ensure that pouch cuts at fixed length thereby ensuring uniform pouch size, design of pouch is always in place which results in marketing appeal. 4) Low operating Cost: Machine has low operating cost associated with it and no complex parts / spares / consumables. Consumables include heaters / blades etc. These are readily available in market. Shipping Policy v Given price offer is FOB India port bases after custom clearance. (Equipment will be supplied in sea worthy wooden pallets). Sea freight up to buyer's destination will be paid by buyer in advance including all destination charges as mention in our shipping Policy. Return Policy Goods sold are not returnable. We Warranty to repair free of cost any component found to be defective due to bad workmanship or faulty raw materials, but not defected due to damage during Transit, Bad Storage or Mishandling of the Equipment. Trial on Machine The customer shall deliver the following items for trial of the machine at our works: a) Laminate roll /Packaging material (At least 3Kg.) b) Sufficient quantity of each of the products proposed to be packed. The above items will be arranged for deliver at our factory (free of cost, inclusive of taxes/delivery charges etc.) by the buyer. Witnessing of trial We take trials at our works before dispatch of machine to fine tune & ensure trouble free operation of the machine. Customer representative may have to reach our works as per the dates communicated by us to them. Installation & Commissioning v Customer is requested to keep ready the prerequisites/ utilities/ accessories at site prior to arrival of our service engineer. v Air ticket to & fro + Lodging, boarding (International standard), local conveyance & USD 60.00 per day per person as pocket allowance for Installation Engineer. Deputation of service engineer during warranty period Air ticket to & fro + Lodging, boarding (International standard), local conveyance & USD 60.00 per day per person as pocket allowance for service engineer Required Information These all machines are customized and we have to manufacture the machine exactly as per customer requirement. so we need following information from customer side in order to initiate the manufacturing process. 1. Product to be packed.....? 2. quantity/weight/volume to be filled in per pouch....? (in gm. or in oz) 3. pouch sealing type.......? (3 side/ 4 side/ center seal) 4. sealing impression....? (lining/ knurling/ plane) 5. batch coding unit to print MRP, LOT no. & Packing Date (Required or not) 6. Production capacity required Per Hour.....?

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	GENIUS
Country/Region of Manufacture	India
Model	GE-70M
