Sadelco Minimax 800 Signal Level Catv Meter Frequency Range: 5-:-872 Mhz

US $325.00

Marina del Rey, California, United States
Feb 13th

Open on mobile:
QR code

Sadelco MiniMax 800 Signal Level CATV Meter Frequency Range: 5-:-872 MHz (working and in excellent condition) * Standard Channel Plans:EIA (NTSC), HRC, IRC, AIRVHF, UHF, FM, PAL and Custom Channel Plans available on request. * Tuning Increments * Frequency Mode: 125 KHz * Channel Mode: 6, 7, or 8 MHz * Frequency Accuracy: ± 20 KHz * IF Bandwidth: 280 KHz at 3dB points * FM Selectivity: Will distinguish 2 FM signals of similar amplitude 300 Khz apart * Measurement Range: 30 to +50 dBmV (+30 to +110dBuV) * Amplitude Accuracy; ± 1.0 dB at 77° F; ± 2.0 dB from 0° 120° F * Auto Calibration: Each measurement computer corrected for level, attenuator setting and temperature * Internal Calibrator: ± 0.25 dB, 4.5 864 MHz white noise source Attenuator * Range: 40 dB autoranging, computer corrected * Input: 75 ohm, user replaceable F81 connector, BNC available on request. Display * Digital LCD: Indicates channel, frequency and signal level in dBmB (switchable to dBuV) Dimensions: * 8.5" L x 4" W x 2.5" D * 21 cm x 10 cm x 6 cm * Weight: 3.1 lbs (1.4 Kg), including case and 24VDC 500Ma AC adaptor. Accurate Under All Conditions Internal White Noise Generator Guaranteed + 1dB accuracy, + 0.5 typical. Measures Digital Channels Average Power of QAM Signals Easy to Operate Fast Digital Tuning Auto Ranging Digital Display Favorite Channels Built to Last Sealed AllWeather Keypad Metal Housing Padded Nylon Bag New Neverbreak "F" Connector C/N and Hum Check Picture Quality Electronic Shut Off Saves Battery Power and Increased Time Between Charges Features * C/N: Range > 50 dB with external preselector * C/N Accuracy: ± 2 dB * Hum: 0.5 5%, ± 0.3%, detects all hum up to 600 Hz. * Favorite Channels: 9 user Programmable Channels. * Delta PA: Automatically calculates and displays difference between picture and audio levels of same channel. * Audio: Adjustable volume, waterproof mylar speaker. * Illumination: Switchable lights for night work * Battery Test: Shows battery voltage and elapsed time * Power Supply: Builtin NiCads provide >16 hrs of normal intermittent use * Electronic ShutOff: User adjustable, 5 min, 10 min or continuous * Digital Channel Measurement: Measures average power of QAM signals Specifications * Frequency Range: 5-:- 872 MHz

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	SADELCO
Country/Region of Manufacture	United States
Model	MiniMax 800
