Schaublin To 70-80 Precision Toolmaker's Lathe Operating And Parts Manual 1039

US $65.00

Nixa, Missouri, United States
Jan 30th

Open on mobile:
QR code

Untitled Document Free, Fast Shipping Every Business Day! See All Categories How-to Books Lathe Practices Series Lathe Operations Milling Operations Grinding Operations Metalworking Woodworking Brands Schaublin Model TO 70-80 Toolmaker's Lathe Instructions and Parts Manual Manual Description: Number of Pages: 21+2 foldouts This is a reproduction, not a photocopy, of an original Schaublin Version No. 4 TO 70-80 Precision Toolmaker's Lathes Operating Instructions and Parts Manual. This manual contains information on proper maintenance lubricating instructions for this lathe. It has information on how to replace the belts on the motor-and-countershaft assembly. It also explains how to properly set the braking time and setting the engaging force, and it contains a foldout with cross sectional view parts diagram of the 70.81.030 Motor-and-Countershaft, Brake Assembly. This manual provides instructions on how to dismantle the headstock and how to set the bearing preload. It also covers how to fit and operate the lever-operated quick-closing attachment as well as how to replace the closing dogs. The manual has a foldout with cross-sectional view parts diagrams of the 70-31 headstock with the quick-closing attachment. It then covers how to adjust the screw-operated carriage 70-45 and provides a specifications sheet on it. Then a explosive view parts diagram of the Leroy-Somer motor, and an electrical wiring diagram. If you have one of these lathes, I would also recommend the catalog on the Schaublin No. 70 Series Precision Lathes. It contains a lot of information on the accessories and tooling options for these lathes. Overview: I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear. Click here to see other work I do, and pictures of my shop. From our shop to yours. We get this. But you get this! Why settle for anything less? Check out my other manuals. Shipping: Returns: Contact Us: I may be running machinery, or I may be mailing manuals, and can't hear the phone. If so, please leave a voicemail and I guarantee that I will get back with you. Click here to see other work I do, and pictures of my shop. Be sure to add me to your favorites list, and check out our other items! I may have more than one manual that covers your machine, and I am adding new manuals all the time. I do not carry additional parts for machinery, except for what is listed. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
