Schlage Pim400-td2 Panel Interface Module Access Control Wireless Access

US $359.99

Narberth, Pennsylvania, United States
Mar 24th

Open on mobile:
QR code

I have 1 new, unused Schlage Electronics PIM400-TD2 Panel Interface Module. The item will come repackaged without original box. Panel interface module wirelessly connects up to two electrical lockset assemblies to an access control panel Data transmission is AES 128-bit-key encrypted for increased security Dynamic channel switching promotes a strong signal by preventing radiofrequency interference Thirteen LEDs indicate the status of all inputs and outputs as well as whether the enclosure is closed or open to prevent tampering Works with up to two Schlage AD-400 series electronic door locksets and an access control panel (sold separately) The Schlage Electronics PIM400-TD2 panel interface module creates a wireless connection between up to two Schlage AD-400 series electronic door lockset assemblies and an access control panel (sold separately) to minimize wiring and enable remote access points. Transmitted data can be AES 128-bit-key encrypted for increased security. The dynamic channel switching promotes a strong signal by preventing radiofrequency interference. Thirteen LEDs indicate the status of all inputs and outputs. A tamper switch registers when the enclosure is open and uses the LEDs to indicate tampering. A remote antenna (sold separately) can be connected for increased signal strength. Power supply sold separately. Specifications Specifications met Certified to NEMA 1, 4, 4X, and 6. Meets UL 294, FFC Part 15, RoHS, and Industry Canada (IC) specifications. Frequency range 902 to 928 MHz Modulation 900 MHz spread spectrum, direct sequence, 10 channels System interface Wiegand (data1/data0) or magnetic stripe (Clock & Data) Connection requirements RS-485 cable to connect to lock; Wiegand or Clock & Data wire to connect to access control panel Communication range Up to 200 ft. (61 m) with obstructions. Up to 1,000 ft. (305 m) clear line of sight. Up to 2,000 ft. (609 m) line of sight with high gain antenna on PIM400. Up to 4,000 ft. (1,219 m) line of sight with high gain antennas on PIM400 and WRI400. Overall dimensions 7.1 x 7.1 x 3.0 inches/18.0 x 18.0 x 7.6 cm (H x W x D)* Current requirement Up to 250 mA Voltage range 9.5 to 26V Power supply 12 or 24V Weight 1.25 lb. (0.56 kg) *H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front. For more information, see the manufacturer's literature. Schlage Electronics, an Allegion brand, manufactures security products for commercial and residential use. Allegion is headquartered in Carmel, IN.

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	Schlage
Type	Panel Interface Module
Model	PIM400-TD2
Country/Region of Manufacture	Unknown
MPN	PIM400-TD2
