Serial 13.56mhz Rfid Reader/writer Module Kits-arduino Compatible With Software

US $16.98

Shenzhen, China
Jun 9th

Open on mobile:
QR code

Serial 13.56MHZ RFID Reader/Writer Module Kits - Arduino Compatible with Software Introduction This RFID module is desgined based on MFRC522. It is a highly integrated reader/writer for contactless communication at 13.56MHz. It supports ISO 14443A/MIFARE mode and MIFARE Classic (e.g. MIFARE Standard) products. Contactless communication using MIFARE higher transfer speeds up to 848kbit/s in both directions. We embeded an MCU on this module. By sending command via UART interface, you can make it work. Operation is very easy. Most work is done by the embeded MCU. There is also a SPI interface on the board. This is the MFRC's SPI. You can access MFRC directly via this inteface. Various host interfaces are implemented on this module: SPI interface Serial UART Features Highly integrated analog circuitry to demodulate and decode responses Supports ISO/IEC14443A/MIFARE Typical operating distance in Reader/Writer mode for communication to a ISO/IEC14443A / MIFARE is 40~50 mm Supports MIFARE Classic encryption in Reader/Writer mode Supports ISO/IEC14443A higher transfer speed communication up to 848kbit/s Control by Serial UART interface: Baud rate could be 2400bps ~ 115200bps, with default baud rate 9600bps With the chip ISO14443, it supports MIFARE standard encryption algorithm Configuration data is preserved in EEPROM against power cut off Built-in 8K EEPROM, easy to access it by sending commands Easy to use, by sending simple commands users can control it to read or write cards In compact command, command is as short as one byte Excellent EMC performance Parameter Power Supply: 4.5V~5.5V, typically 5V. Interface: UART (5V TTL) and SPI (3.3V TTL) Size: 40mm x 50mm Usage Baud rate could be 2400bps ~ 115200bps Default setting: Baud Rate: 9600bps Parity bit: None Start bit: 1 Data bit: 8 Stop bit: 1 There are two kinds of command: Basic command and compact command. All the command are in Hex format. Please download manual for more information. Connecting with Arduino is pretty easy. With Arduino Sensor Shield, just plug in and play. It could do: Basic command send/receive window Find card Read card's serial NO. Add/remove card from authorization list Check card in the list Read/write RFID card Read/write EEPROM You could download here: RFID_Tool.zip User Guide Document Manual Mifare S50 Mifare S70 MFRC522 Datasheet Testing with Arduino Package Contains: 1 x RFID module 2 x MIFARE1 S50 suqare white card 1 x MIFARE1 S50 key card 1 x 4-pin wire

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded/Generic
Country/Region of Manufacture	China
