Sheldon 10 Inch L Series Lathe Parts Manual

US $22.00

  • South Lyme, Connecticut, United States
  • Jan 30th
Open on mobile:
QR code
Document Title: Sheldon 10 Inch L Series Lathe Parts Manual Number Of Pages: 32 Condition Of Original: Good Scan Type: Grayscaled and Black & White Images and Text Scan Quality: Good Description: This manual covers general parts for Sheldon L series lathes with 10 inch swing and 3/4 inch collet capacity. The first five or six pages are catalog pages that cover general descriptions of accessories and tooling. The next couple pages cover installation and setup and V-belt replacement, then a page covering cleaning and lubrication. The remainder of the manual breaks the machine down by major component groups with number indexed exploded drawings and associated list of part descriptions. The last couple pages cover parts and operational instructions for the metric threading attachment. No specific print dates or serial number range but this appears to be from the mid-fifties. This copy cleaned up really well and is probably a better quality than any existing original today. Product Media: Your choice of Hardcopy or Electronic format on CD-ROM Formats Available (you may choose one of the following): Paper Hardcopy, or Adobe Acrobat PDF (.pdf). Sample Page:
