Skg16b Bluetooth/rs232/usb Uart Gps Module Demo Board

US $91

shenzhen, China
Jan 29th

Open on mobile:
QR code

????? You are purchasing Mini USB & Bluetooth Interface GPS Demo Board(MB-CM12118) Read Notice Tips carefully under the pictures before you buy them. Upgrade shipping to TNT express or Regitstered Air Mail Service: For all bills with final value over $19.9, we will use registered air mail to ship them for free. Otherwise if your bill is less than 19.9 and you want registered airmail shipping, please add $2 when finishing payment. For all shipping to West and North Europe, USA, Canada, and Australia, we provide a $10 upgrade service to TNT express, no matter how many items you purchase or what the final weight is. Items will arrive in 3-5 working days and get much better care in the shipment. We strongly suggest our customer to choose this service. We provide a great discount in UPS and FEDEX service to USA and Canada too, contact us for more information. EU countries list: UK, Denmark, Finland, France, Greece, Ireland, Luxemburg, Germany, Italy, Netherland, Norway, Portugal, Spain, Swiss, Switzerland and Malta. Do not adjust the final amount when finishing payment if you are not going to upgrade your shipping. Picture Showcase Description Brief Introduction: This item is the latest GPS demo board provided by Sure Electronics which utilizes SKG16B by MStar Technology as the receiver of this item. Compared with the old version which employs Ublx TIM-LC module, this version is smaller in size and faster in speed. Moreover, its sensitivity and accuracy are also improved. It supports NMEA 0183 V3.01 standard. Interfaces that can suit the requirements of different applications like USB, RS232 and bluetooth are also integrated to facilitate its use. An external magnetic antenna is provided with this module. Net Weight:200g /7.1oz Features: Low Power consumption Powered by USB port, no need to feed with DC power supply RF Receiver of Noise Figure is at 2.5 dB High Sensitivity -161 dBm( indoor) Seamless Outdoor/Indoor Operation Support standard NMEA-0183 V 3.01 Graphic GPS testing software is provided for free Software for modifying baud rate is provided for free Interfaces: USB Mini-B and USB B interface, RS232 Female Interface, bluetooth Specifications: Absolute Maximum Ratings: Supply voltage: 5.4 V Supply current: 500 mA Operating range: -20~+70 °C Storage range: -20~+70 °C Relative Humidity: 5~80 % DC Power: Supply voltage: 5.1(typical) V Supply current:: 50(typical) mA General: Frequency 1575.42 MHz C/A code 1.023 MHz Acquisition Channel 48 Tracking Channel 12 Accuracy: Position CEP 2 m Velocity 0.1 m/s Time 20 ns Datum: WGS-84 Default WGS84 Time To First Fix(TTFF): Hot start <2 seconds Warm start <32 seconds Cold start <35 seconds Sensitivity: Tracking Sensitivity: -161(typical) dBm Acquisition Sensitivity: -142(typical) dBm Antenna: Type: Active patch antenna Center Frequency: 1575.42±1.032 MHz Polarization: RHCP Impedance: 50 Ohm USB Interface: Comply with relative descriptions of electrical characteristics of USB V2.0 standard RS232 Interface: Comply with relative descriptions of electrical characteristics in RS-232F standard Bluetooth Interface: Comply with relative descriptions of Bluetooth Interfacev2.0 Serial Port Profile(SPP) Password: ’0000’or ’ 1234’ Communication: Default baud rate: 9600 bps Baud rate supported: 9600 bps Navigation update rate: 1 Hz Protocol Message: NMEA-0183 V3.01 Applications: GPS receiver application Automotive application Car navigation and tracking External GPS Devices Ideal for PC, PDA and other consumer devices Develop your own GPS navigation system or connect to a pocket PC for a low cost navigation system. Use in the car or boat for trip recording and distance to destination information. Package Contents: Mini USB & Bluetooth Interface GPS Demo Boardx1 External magnetic antenna SMA connector for GPS receiver x1 Mini USB cablex1 Go to Download Center for Manual, Driver and Tutorial. Keyword: GP-GS010 Note: The accessories might be a little different from what you've seen on webpage since the accessories you received might be from different batch. However, it won't affect your use. Sure Electronics assumes no liability for any ambiguity caused by the product photos. Related software has been proven to function well under Windows XP SP2, so we will not provide technical support. Shipping & Handling Payment Method Refund and Return On Jul-26-13 at 20:55:55 PDT, seller added the following information:
