Smc Rotary Adapter, R 1/8 Male, Push In 6 Mm

US $15.32

Halesowen, United Kingdom
Sep 4th

Open on mobile:
QR code

The KS series from SMC are rotary one-touch fittings with a double ball race bearing for high speed applications. This series is suitable for vacuum or pressure applications, applicable to use for oscillating and rotating sections in robots. Ball race bearing for oscillating or 360? rotating applications One-touch collet includes anti tube-rotation mechanism Maximum rotational speed 500rpm (4/6mm), 400rpm (8mm) Low torque rotation style Copper-free specifications Electro less nickel plated stud Thread-to-Tube Adaptors Maximum operating pressure 10 bar Maximum vacuum operating pressure -100kPa Proof pressure 3MPa Ambient and fluid temperature -5 to +60?C (water 0 - 40?C) All thread sizes are specified as R(PT) (taper) type Our eBay Store Add to Favorite Sellers Contact Us Bearings Fluid Power Lubricant PPE Tools SMC Rotary Adapter, R 1/8 Male, Push In 6 Mm $15.32 The KS series from SMC are rotary one-touch fittings with a double ball race bearing for high speed applications. This series is suitable for vacuum or pressure applications, applicable to use for oscillating and rotating sections in robots. Ball race bearing for oscillating or 360? rotating applications One-touch collet includes anti tube-rotation mechanism Maximum rotational speed 500rpm (4/6mm), 400rpm (8mm) Low torque rotation style Copper-free specifications Electro less nickel plated stud Thread-to-Tube Adaptors Maximum operating pressure 10 bar Maximum vacuum operating pressure -100kPa Proof pressure 3MPa Ambient and fluid temperature -5 to +60?C (water 0 - 40?C) All thread sizes are specified as R(PT) (taper) type Product Description The KS series from SMC are rotary one-touch fittings with a double ball race bearing for high speed applications. This series is suitable for vacuum or pressure applications, applicable to use for oscillating and rotating sections in robots. Ball race bearing for oscillating or 360? rotating applications One-touch collet includes anti tube-rotation mechanism Maximum rotational speed 500rpm (4/6mm), 400rpm (8mm) Low torque rotation style Copper-free specifications Electro less nickel plated stud Thread-to-Tube Adaptors Sealant coated threads minimise assembly time. The fittings can be used on vacuum or positive pressure lines. Suitable for use with nylon, soft nylon or polyurethane tube for compressed air or water (general industry) conveyance Maximum operating pressure 10 bar Maximum vacuum operating pressure -100kPa Proof pressure 3MPa Ambient and fluid temperature -5 to +60?C (water 0 - 40?C) All thread sizes are specified as R(PT) (taper) type Lightning Fast Shipping Excellent Customer Service About Us World of Supply is a UK-based online distributor of leading-brand engineering, DIY and business consumables. Our site located in the heart of the UK houses both our administrative and warehousing facilities. Experienced Team Our team is very experienced within the online realm, we can turn around products extremely efficiently at an affordable price. Product Support We can offer high quality support on your journey with us. Please feel free to contact us regarding any product questions no matter how simple or complex. World Of Supply - Tel: 0121 585 5920 Shelah Rd, Halesowen B63 3XL

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	SMC
Type	N/A
MPN	KSL06-01S
EAN	0713049178356
