Smh Flashrunner Quattro Series Standalone In-system Programmer Fro4cb01

US $4,200.00

Ambridge, Pennsylvania, United States
Feb 23rd

Open on mobile:
QR code

SMH FlashRunner Quattro Series High Performance Standalone,In-System Programmer FRO4CB01 4 Channel Parallel. This system was retired from service and was functioning at the time of removal. Only what it in the photo is included, some custom made cables for the specific application is included. All software and information on the system can be downloaded from the SMH website. Overview FlashRunner Quattro is a high-integration in-system gang programmer, based on the FlashRunner technology. FlashRunner Quattro is designed for programming multi-PCB panel assemblies. This means: Extremely fast programming (it is one of the fastest in-system programming system on the market); Standalone operations (projects and code images stored on memory cards); Compact and robust design for production environments. FlashRunner Quattro is composed of a mainboard which hosts the programming and demultiplexing modules, plus various connectors used to interface to the target system and host/ATE. Hardware Features FlashRunner features state-of-the-art electronics to provide you with high integration flexibility in a compact footprint. 9 to 18V DC power supply input; Six digital I/O lines; Two digital I/O or analog output lines; Two programmable output voltages; One programmable clock output; Secure Digital memory cards (up to 2 GB); 512 bytes on-board dynamic memory; On-board timekeeper and calendar; Optoisolated inputs for project selection; Two optoisolated command inputs (START and STOP); Three optoisolated status outputs (FAIL, PASS, BUSY); Optoisolated RS-232/Ethernet channel. FlashRunner's open architecture makes its firmware easily upgradable to support both new devices and new features. Software Features FlashRunner is set up and controlled via ASCII-based commands. FlashRunner can receive and execute commands in two ways: Over the RS-232 or Ethernet connection (Host mode); Via "scripts" stored in its SD card (Standalone mode). In the first case, FlashRunner is controlled by a host system (e.g. Windows HyperTerminal); in the latter case, FlashRunner works in standalone mode and is fully autonomous. Fully autonomous standalone mode thanks to its SD memory cards (FAT16); Controllable by any host system through a terminal utility and simple ASCII protocol; Unlimited projects (scripts); Interface Library DLL to control the instrument from within user written applications; Optional Data Protection System to make the contents of the binary file to be programmed to the target device not readable (and not duplicable) by non-authorized people; Log files; Erase, blank check, program, read, verify, oscillator trimming, etc. FlashRunner comes with a Windows utility that allows you to communicate with the instrument and perform the most common operations: send commands, manage SD card files, update the instrument's firmware, etc.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	SMH Technologies
Model	FR04CB01
