Spectrum Analyzer Analyser 150k-1ghz With Tracking Generator 110-220v At5011a(b)

US $956.02

china, China
Jan 29th

Open on mobile:
QR code

This ebay listing include: Spectrum Analyzer Analyser 150K-1GHz with Tracking Generator 110-220V AT5011A Features Frequency range: 0.15 ~ 1050MHz 4 half figures (center frequency, 0.1MHz Resolution) -100 ~ +13 dbm amplitude range, 20KHz, 400KHz IF filter bandwidth and 4KHz video Tracking generator Output range: +0 ~-50dBm (50Ohm) Function CATV and communications machine inspection: with the impedance converter (50 Ohm converter to 75 Ohm) GSM, CDMA mobile phone repair Point frequency mode and Sweep mode Frequency Measurement Extension With the Frequency Expander AT5000-F1, the measure frequency can expand to 2000MHz (qualitative measurement), the measuring range is 1050 MHz ~ 2050 MHz. But it can only be used for input channel expansion, not suitable to the Tracking Generator. With the Frequency Expander AT5000-F2, the measure frequency can expand to 3000MHz (qualitative measurement), the measuring range is 2050 MHz ~ 3050 MHz. But it can only be used for input channel expansion, not suitable to the Tracking Generator. Electromagnetic Compatibility Test (EMC) Conducted interference test: With the AT-166 conducted interference interface (only a little stock, not produced now) Radiated interference test: With the AZ-530-E electric field monopole probe Internal Circuit Interference test: With the AZ-530-M magnetic field probe Internal circuit Checking and repairing Test: With the AZ-530-H high-impedance probe Specifications Frequency Range: 0.15 ~ 1050MHz Center frequency display accuracy: plus or minus 2% × spectral width of +5 × 10^-3 × center frequency +100 KHz Tag accuracy: plus or minus 0.1% bandwidth +100 HKz Frequency Display Resolution: 100KHz (4 ?-digit LED) Sweep width: 100KHz / cell ~ 100MHz / 125 block grid and 0Hz / cell (0 scan), accuracy: plus or minus 10% Frequency stability: better than 150KHz / hour IF Bandwidth (-3dB): 20KHz (plus or minus 50%); 400KHz + (0, -40%), video filter (pass); 4KHz Scan Rate: 43Hz Margin Range: -100 ~ +13 dBm Screen display range: 80dB (10dB / cell) Reference Level:-27dB at 500MHz Department The average noise level:-90dBm (20KHz bandwidth, typical dBm) Distortion: 2 3rd harmonic <-55dBc 3-order intermodulation:-70dBc Sensitivity: Better than-90dBm Log scale fidelity: plus or minus 2dB (without attenuator), 500MHz Input / Output Impedance: 50Ohm Socket: N (F) connector Attenuator: 0 ~ 40dB (4 × 10dB step) Input attenuator accuracy: plus or minus 1dB/10dB Maximum input level: +10 dBm, plus or minus 25VDC (Attenuator 0dB), +20 dBm (40dB attenuator) Others Power: 200VAC/110 VAC plus or minus 10%, 50Hz ~ 60Hz Track calibration: adjustment in the panel (TR) Power: 20W plus or minus 20% Protection: Security 1 (IEC1010-1) Size: 285 (W) × 125 (H) × 380 (D) mm Net Weight: 9.5 kg,the packaged weight can be up to 11Kg. Tracking generator Output Frequency Range: 0.15MHz ~ 1050MHz Output Level Range: -50 ~ +1 dBm (10dB variable step adjustment) Output attenuator: 0 ~ 40dB (4 × 10dB) Accuracy (attenuator): plus or minus 1dB Output impedance: 50Ohm (BNC) Frequency range: 0.15 ~ 1050MHz Frequency response: plus or minus 1.5dB Radio frequency interference (RFI): <20dB *********************************************************************************************************** Any request please contact us! :-) If you want to delivery to eastern Europe/Finland/Norway, please ask me about postage before bid. returns Dear buyers, we appreciate your business, if you are satisfied with our service, please leave us a positive feedback and rate the details of the transaction (Detailed Seller Ratings) with a "PERFECT 5 STARS ". [When you rate the shipping time part please take international transit into consideration.] Your recognition will make us more confident to develop business and serve you better. Our goal is to make sure you are a happy buyer and pleasant shopping with us. Please email us before leaving any 1 or 2 ratings, negative/neutral feedback or open any dispute. We understand the concerns and frustrations you might have, and will do our endeavor to resolve the issues. Please give us the opportunity to resolve any problem. Our system automatically returns feedback once it is left for us. Shipping (Other countries or remote areas may take longer.) If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction! We will NOT be responsible for any delay during delivery including but not limited to customs postage checking, strike, force majeure etc We will post the item to the address of your Paypal registered . Please ensure your address is correct. If the item returns to us without fault, buyer will pay the shipping and handling fees again (except if we print a wrong shipping label). Your partner for managing your online business
