Speedline Mpm Accuflex Screen Printer

US $35,000.00

Concord, North Carolina, United States
Jan 30th

Open on mobile:
QR code

MPM Speedline ACCUFLEX Screen Printer Model: Accuflex Vintage: 2005 2D post inspection Rotary Pin Placement Option Pressure Feedback Control Squeegee Head Underwipe Stencil Cleaner Fiducial Recognition for Stencil to PCA Alignment Auto vision system SPC package Vacuum under stencil cleaner with solvent Programmable self leveling print head Board edge clamping system Fixed front rail Auto rail width adjust AccuPro software rev. 8.4 or higher Standard 29x29 frame size Please click on the link below to see the Accuflex in operation at Recon.inc http://youtu.be/rkKZddX8Ezg B O A R D H A N D L I N G Maximum Board Size (X x Y) 23" x 20" (584mm x 508mm) Minimum Board Size (X x Y) 3" x 2" (75mm x 50mm) Board Thickness 0.03" to 0.20" including warpage, (0.8mm to 5.0mm) Maximum Board Weight 10 lbs. (4.5kg) Minimum Board Edge Clearance 0.19" (5mm), 0.12" (3mm) - Optional Maximum Underside Clearance 0.59" (15mm) Transport Speed Adjustable Transport Height From Floor 34" - 38 Transport Track Feed Direction Left-to-Right, Right-to-Left, Left-to-Left and Right-to-Right Triple Track Conveyor Lengths 52" (1320mm), 60" (1524mm), 68" (1727mm) Method of Board Hold-Down Positive edge-clamps (front and rear) Method of Board Support Independent, moveable magnetic support pins P R I N T P A R A M E T E R S Maximum Print Area (X x Y) 22" x 19.6" (559mm x 498mm) Snap-off Speed 0.008" - 0.39"/sec, (0.2mm - 10mm/sec) Print Speed 0.2" - 7.87"/sec, (5mm - 200mm/sec) Print Pressure Up to 44 lbs (20 kg) Print Stroke 20" (508mm) Stencil Frame Size 29" x 29" (737mm x 737mm) standard Smaller Frame Accommodations By use of optional Adapters V I S I O N Vision Field-of-View (FOV) 0.40" x 0.40" (10mm x 10mm) Fiducial Types Standard shape fiducials. See SMEMA standards. Camera System Single roving camera module with dual beam optics P E R F O R M A N C E Vision Alignment Repeatability +/- 0.001” (+/- 0.025mm) at 6 sigma (Cp greater than or equal to 2.0*) verified with glass plate capability test** Vision Alignment Accuracy +/- 0.001” (+/- 0.025mm) at 6 sigma (Cp greater than or equal to 2.0*) verified with CeTaQ™ CmController™ capability test** Print Deposit Repeatability and Accuracy +/- 0.002” (+/- .050mm) at 6 sigma (Cp greater than or equal to 2.0*) verified with CeTaQ™ CmController™ capability test** CYCLE TIME Standard Performance 16.2 seconds*** Speed Enhancement Package 12.5 seconds*** Speed Enhancement Package , Triple Track Conveyor System - 11.0 seconds*** F A C I L I T I E S Power Requirements 110 - 240V, 50/60Hz (+/-10%) Air Supply Requirements **** 5 CFM at 90 psi, Clean Air Supply Height 62" (1575 mm) Depth 57" (1448 mm) Width - Standard Performance 51.7" (1314 mm) Width - High Performance 52" (1320 mm), 60" (1524 mm), 68" (1727 mm) Buyer is responsible for all shipping and skidding costs. We have a crating company onsite and can assist with packup and logistics. Mankind Electronics Machinery dba Recon Inc. Agizzi@reconsales.com 704-795-6610
