St-link/v2 (mini) Programmer Stm8 Stm32 In-circuit Debugger Usb2.0 With Swim Swd

US $12.99

shenzhen, guangdong, China
Jan 29th

Open on mobile:
QR code

This auction is for ST-LINK/V2 (mini) Mini ST-LINK/V2, in-circuit debugger/programmer for STM8 and STM32 Description Mini ST-LINK/V2 on a small single board, an extreme low cost solution for in-circuit debugger/programmer for STM8 and STM32. Features Onboard 500mA self-recovery fuse to avoid harming by short circuit Dual voltage output (3.3V/5V), easy for debugging/programming Standard USB interface for direct connection to PC Debugging/Programing performance Debugging : run at full-speed, single-stepped, breakpoints, viewing variables and registers, etc. Programming : supports FLASH ROM, EEPROM, AFR, etc. USB2.0 combined with SWIM/SWD interfaces : quick response for debugging & fast speed for programming Upgradable firmware The firmware is upgradable to support more devices in the future Automatically upgraded Supported software ST-LINK Utility v2.0 (or higher ver.) STVD Version 4.2.1 (or higher ver.) STVP Version 3.2.3 (or higher ver.) IAR EWARM Revision v6.20 (or higher ver.) IAR EWSTM8 Revision v1.30 (or higher ver.) KEIL RVMDK Revision v4.21 (or higher ver.) ATOLLIC TASKING Supported devices All the STM8 devices with SWIM interface All the STM32 devices with SWD interface Photos ST-LINK/V2 (mini) Vs ST-LINK/V2 Vs ST-LINK Compare ST-LINK/V2 (mini) ST-LINK/V2 ST-LINK Remarks SWD voltage range 1.65V - 3.6V 1.65V - 3.6V 3V - 3.6V ST-LINK/V2 and ST-LINK/V2 (mini) support STM32 low voltage devices SWIM voltage range 1.65V - 5.5V 1.65V - 5.5V 1.65V - 5.5V Supports SWV YES YES NO For the moment, only STM32 supports SWV while STM8 doesn't Debug interfaces 2 2 1 ST-LINK/V2 and ST-LINK/V2 (mini) support STM8/STM32 with separated interfaces LED indicator Dual color LED Dual color LED Red LED Dual color LED allows indicating more status Fuse YES NO NO Fuse for avoid harming by short circuit Connecting with PC While connecting the ST-LINK/V2 (mini) to the computer through USB interface, the USB driver is required and should be installed correctly first. Click on the link to download : ST-LINK/V2 USB driver for Windows 7, Vista and XP Connection with STM8/STM32 Applications The ST-LINK/V2 (mini) should be connected to the STM8 application via the SWIM interface. Debugger Pin Target Board Pin Description VCC MCU VCC STM8 VCC SWIM MCU SWIM STM8 SWIM PIN GND GND STM8 GND RST MCU RESET STM8 RESET PIN The ST-LINK/V2 (mini) should be connected to the STM32 application via the SWD interface. Debugger Pin Target Board Pin Description VCC MCU VCC STM32 VCC SWDIO MCU SWDIO STM32 SWD SWDIO GND GND STM32 GND SWCLK MCU SWCLK STM32 SWD SWCLK Please note that the VCC and GND should be connected correctly to avoid any harm to the ST-LINK/V2 (mini). Package Contains ST-LINK/V2 (mini) x 1 4-pin custom connector cable x 1 Terms & Conditions Payment: · PayPal is the only method of payment that we accept. Shipping: · We ship items to Worldwide! · Please confirm your address in paypal, phone number is also very important. · All items will be shipped within 48 working hours on receipt of cleared payment. · We'll add a tracking number after sending the item so that you can track your parcel. Returns Policy: · We are happy to return any unused item in its original packaging within 14 days of delivery. · Buyers are responsible for the round(two-way) shipping cost. Feedback: · We'll leave POSITIVE FEEDBACK on receipt of cleared payment. · If you're satisfied with the item and our service, please leave POSITIVE FEEDBACK, it's important to us. · Once any problems occured, please contact us first. We'll try our best to work things out. FAQ: · More details(Click) If you have any question, please feel free to contact us. It's our pleasure to serve you! We appreciate your business!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Waveshare
Interface to Target	SWIM / SWD
Model	ST-LINK/V2 (mini)
Interface to PC	USB 2.0 full speed (USB driver required)
Country/Region of Manufacture	China
Programming	Programs FLASH ROM, EEPROM, AFR, Security-bits, et
Designed for	STM8 and STM32
