Standard Drill Press Servo 7060

US $1800

San Jose, California, United States
Feb 27th

Open on mobile:
QR code

Standar Drill Preess Servo 7060 used good condition Standard Drill Press For laboratory, prototype and precision production work. Available in chuck and collet models, 12" or 19" column, and inch or metric calibration. Inch and Metric versions Drill holes down to 0.002” / 0.05mm Dia. Spindle runout: 0.0002" / 0.005 mm TIR High accuracy down stop for drilling depth control (0.001” / 0.05mm per division) Variable speed spindle (200-20,000 RPM) Quill travel (stroke): 1.5” / 38.1mm Keyless Albrecht chuck versions for quick and easy drill change; standard 0-1/8" / 0-3 mm; optional 0-1/16" / 0-1.5 mm WW collet versions for less run out and improved accuracy; 0.0039"-0.252" / 0.1-6.4 mm collet sizes available Graduated dial gauge for depth control (0.001” / 0.05mm per division) Wide selection of bases and accessories Drill capacity:to 1/16" in inconel to 1/8" in steel to 3/16" in aluminum (collet only) Electrical: 115 volts AC, 50/60 Hz, 2 amps (220V/115V transformer available) The Pictures Shown are the Actual Item you are Bidding on. Standard Drill Press Models 7000/7100 7010/7110 7050/7150 7060/7160 Drill Press with Unique Offset Column 7030/7130 Drill Press with Elbow and Deep Throat 7040/7140 7070/7170 I=Inch; M=Metric [ ] = See drawings 7000-I 7100-M 7010-I 7110-M 7050-I 7150-M 7060-I 7160-M 7030-I 7130-M 7040-I 7140-M 7070-I 7170-M Chuck or collet Chuck Chuck Collet Collet Chuck Chuck Collet Maximum distance of chuck/collet to base[a] 6" 152 mm 13" 330 mm 7.5" 190 mm 14.5" 368 mm 6" 152 mm 16.5" 419 mm 18" 457 mm Throat depth [b] (spindle CL to column) 3.5" 89 mm 3.5" 89 mm 3.5" 89 mm 3.5" 89 mm 8.5" 216 mm 9.4" 239 mm 9.4" 239 mm Working base area (width) [c] 6.5" 165 mm 6.5" 165 mm 6.5" 165 mm 6.5" 165 mm 9.75" 248 mm 9.75" 248 mm 9.75" 248 mm Working base area (depth) [d] 6.5" 152 mm 6.5" 152 mm 6.5" 152 mm 6.5" 152 mm 13.25" 324 mm 13.25" 324 mm 13.25" 324 mm Column diameter through head [e] 1.25" 31 mm 1.25" 31 mm 1.25" 31 mm 1.25" 31 mm 1.25" 31 mm 1.25" 31 mm 1.25" 31 mm Column diameter through elbow [f] - - - - - - - - - - 1.625" 41 mm 1.625" 41 mm Column length [g] 12" 305 mm 19" 483 mm 12" 305 mm 19" 483 mm 7.5" 191 mm 18" 457 mm 18" 457 mm Footprint width 7.15" 181 mm 7.15" 181 mm 7.15" 181 mm 7.15" 181 mm 10.5" 267 mm 10.5" 267 mm 10.5" 267 mm Footprint depth 11.8" 299 mm 11.8" 299 mm 11.8" 299 mm 11.8" 299 mm 18.5" 470 mm 18.5" 470 mm 18.5" 470 mm Overall height 18" 457 mm 25" 635 mm 18" 457 mm 25" 635 mm 18" 457 mm 29.5" 749 mm 29.5" 749 mm Weight 21# 9.5 kg 21# 9.5 kg 21# 9.5 kg 21# 9.5 kg 27# 12.2 kg 40# 18.1 kg 40# 18.1 kg Base Fine grain, ground cast iron base Fly-cut cast aluminum base with fine grain cast iron offset and elbow

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	SERVO
Country/Region of Manufacture	United States
Model	7060
