Stm32f103rct6 Development Board /mini System Board Arm Stm32 Cortex M3 Board

US $13.40

Shenzhen, Guangdong, China
Jan 29th

Open on mobile:
QR code

This development board is our cost-effective for you to create a design aesthetic development board, development board , the use of stable , all pin are using high-quality materials made of gold-plated , no longer have to worry about with a long time to appear poor contact phenomenon occur. All functional development boards are individually tested before shipment . Do not worry about quality issues. If you find any problem within a week , you can choose to return , and we are responsible for postage , solve your worries ! The development board is a practical type of STM32 development board, development board all the IO leads are very easy to do secondary development. The following will detail the detailed structure and function of the development board .Introduction [ chip ] 1, STM32 master chip introduced STM32 powerful onboard STM32F103RCT6 chips, its core resource parameters are listed below : Nucleus : Cortex-M3 32-bit RISC; Operating frequency : 72MHz, 1.25 DMIPS / MHz; Operating voltage : 2-3.6V; Pack : LQFP64; I / O ports: 64 ; Storage resources : 256kB Flash, 48kB RAM ( so convenient transplant UCGUI LWIP more resource-intensive protocol packets can develop a more powerful program ) Interface resources : 2xSPI, 5xUSART, 1xI2S, 2xI2C; 1xLCD, 1xSDIO, 1xUSB, 1xCAN; Analog to digital conversion : 3xAD (12, 1us, sharing 16 channels ), 2xDA (12 -bit) ; Debugging Download : Support JTAG / SWD interface debugging downloads, support IAP. 2, the regulator chip Use AMS1117-3.3V chip voltage regulator is 3.3V. Introduction [ interface ] 3, JTAG / SWD interface Download and simulation debugging support . 4, USB interface Power to the circuit board with protection diodes also have two high-capacity electrolytic capacitors ( stable to give external power supply) 5, MCU pin interface Leads all pins , convenience and peripherals I / O connections. 6 ,5V and 3.3V power input and output interfaces Commonly used in the external power supply, or with the user board co manner. ( Multiple sets of power ) 7,4 screw positioning holes ( and with pillars ) 8 , a power switch ( such as a short circuit when the outside world can quickly turn off the power , but can also power external module brings new convenience ) [ Introduction] other devices 12 , the power LED Power- indicator light. 13 , the user LED Facilitate I / O output test or directs the program running. 14 , reset button Easy for users to reset chip program . 15,8M Crystal Through the multiplier setting , so clocked at 72M. 16,32.768K Crystal Built-in RTC for use , or for calibration. [Interface Overview] 17 ,JTAG / SWD interfaceSupport download and debug . USB interface USB can communicate with the PC. USART1 interface You can use USART1 download program, or use USART1 output system information , were observed. MCU pin interface Leads all pins , convenience and peripherals I / O connections. 5V and 3.3V power input and output interfaces Commonly used in the external power supply, or with the user board co manner. shipping PAYMENT TERMS: 1.we only accept payment view paypal , We apologize that we cannot accept other payment methods, such as cheque or postal orders . 2.All major credit cards are accepted through our secure payment processor PayPal 3.Payment must be received within 7 business days of auction closing. SHIPPING TERMS: We will not ship to , Negeria, Italy and some country unless accept the long delivery time( caused by the strict customs) and good communication. 1. Items will be sent within 12-24 hours after the payment cleared. 2. We will ship package to your ebay address only. 3. All orders will be shipped via the International Airmail service by china post air mail or HK Post, The other delivery way also accepted after our confirmation The following is the estimated time as our experience United States / United Kingdom / Australia/Canada 10-20 Business days(Over 25 business days will be resend or refund) Singapore / other included Asia country 15-25 Business days (Over 30 working days will be resend or refund) Germany / France / Belgium / Austria / Netherland / Poland 20-28 business days(Over 32 business days will be resend or refund) Spain / Other un-listed Countries 25-35 business days( Over 40 business days will be resend or refund) Please refer to the Delivery time before you decide to buy. We hope to received your positive feedback. Any problems, Please contact me advance. Our mission is let our customers 100% satisfy under our best service!

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“brand new”
