Str1001000x Rs-485 Board Controller 10 Inputs 5v 12v 24v Home Automation

US $28.30

Sofia, Sofia, Bulgaria
Jan 29th

Open on mobile:
QR code

8 Digital Inputs with Optocouplers, 2 Digital Inputs RS-485 smart programmable controller STR1001000X Digital Inputs 8 0 – 30 V with optocouplers 2 0 - 50V Power +5V(30mA) or +9-24V(20mA for 12V) Dimensions 162 x 31 x 20 mm Weight 38 gr RS-485 smart management line Smart Lock inputs Baud rate (300 – 115200) Fully reprogrammable on the fly without restart Runtime Counter - 4 bytes User Data RAM - 4 bytes User Data EEPROM - 8 bytes Download / Links Document Hardware STR1xxxxxx Commands Software - Windows XP..7, 8 32/64 STR1XX Assistant - Only for Test Software - MacOS STR1XX Assistant - Only for Test You can use any transmitter for the management of this controller. It is enough to maintain the required speed and input impedance is complies with the network. RS-485 smart management line: Unlike any other similar controllers, it checks the correct information, which returns as result. When controller transmits, simultaneously read the information transmitted from RS-485 line. Each byte is compared for validity. When an error is detected, transmission is terminated. This helps to quickly release the line. In case of a short circuit on the line, the transmitter is protected against overload. Smart Lock: Normally, inputs are read at intervals of 40ms. Likely to miss the change of level in short pulses at the input. Especially in large networks. This feature allows you to keep the level of input and extend it. With one command, you can change parameters in multiple controllers. With one command, you can manage several controllers. You can connect different controllers, up to 32, from our series STR1xxxxxx in the same network. Principle of operation of the controller Each controller has its own number, 1-255. This number is stored in one byte. This number can be programmed at any time. Each controller has multiple inputs. Each of them has two numbers. First number: A constant number, starting from 0 to 9 for inputs, for this controller. This number is stored in one byte. This number is used when applying the commands (first set) for accessing specific controller. Example: Controller 5, input 4. Please download PDF file with commands. For each command, you can see an example. The second number can be programmed and changed at any time. It is used for direct access (second set), regardless of controller. This number is stored in two bytes and can be from 1 to 65535(0xFFFF). Example: Intput 123. Please download PDF file with commands. For each command, you can see an example. How to connect the controller to network 1. Set (on/off) jumpers for resistor for RS-485 line 2. Power the controller 3. Connect controller to RS-485 line 4. Program new controller number 5. Program new inputs number for direct access 6. Set, if needed, data for smart lock inputs 7. Controller is ready for use 8. You can connect next controller ….. Payment method Only Paypal Item will be shipped to Paypal address. Please confirm your shipping address in the PayPal Account Return Policy Please be advised that shipping and handling cost are not refundable. Refund will be sent after we received your returning item. In all cases, buyers pay shipping at their own cost to return products for refund. Shipping Normally, We ship order within 24 hour from Monday to Saturday after the payment is cleared. Combine Shipment - YES. Ask for TOTAL, BEFORE you pay. Once you pay, we cannot make a discount for shipping. The shipping time may vary, depends on receiver's location. Item will be shipped WITH tracking number. Item Declare Your item will be mark as Gift or at a low's value. However, most of our items can reach to buyers without any taxes. We are NOT responsible for any import tax, customs fees or customs delay.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RS-485 programmable controller
Country/Region of Manufacture	Bulgaria
Model	STR1001000X
Country of Manufacture	Bulgaria
MPN	STR1001000X
