Superdroid Robots Dual Ls7366r Quadrature Encoder Buffer, New

US $5300

not set, United States
Jun 23rd

Open on mobile:
QR code

SOCHICDEAL Free Shipping - Fast Shipping - New Products SuperDroid Robots Dual LS7366R Quadrature Encoder Buffer, New Item Description This is SuperDroid Robot's TE-183-002 encoder buffer breakout board based on United States Digital's LS7366R quadrature counter IC. The LS7366R is designed to user interface straight to an encoder output such as the hall-effect encoders on our IG32, IG42, and IG52 gear motors. Equipped with a SPI user interface, the LS7366R makes is easy to keep an eye on the position of the motors and overall range took a trip. The LS7366R can be configured to work with a quadrature output from an encoder or a single pulse and instructions from a single sensor. Depending upon your encoder setup, this breakout board has a series of solder jumpers situated alongside the encoder input headers. To user interface straight to our encoder equipped motors, the solder jumpers should be bridged to make it possible for the required 1k-Ohm pull-up resistors for the motors. If you are interfacing with among our optical encoders the solder jumpers have to be exposed. Documents, support, and sample code can be found on SuperDroid Robotic's site. 32-bit data register and comparator 32-bit programmable counter Measurements: 0.77" x 2.50" Opperating Voltage: 3V to 5V Additional Information N/A x N/A x N/A inches ; N/A pounds Payment option We are accepting PayPal only! Shipping and handling + We ship within one business days of payment, usually sooner. + We use a selection of shipping services such as UPS, FedEx, USPS etc. + Expedited shipping takes between 2-3 business days + We do not ship to AK, HI, PO boxes, or APO addresses. Return policy just in case... You may return most new, unopened items within 14 days of delivery for a refund, minus a 15% restocking fee. If the return is a result of our error, we'll provide a prepaid return label and the restocking fee will be waived. Items must be returned in the condition they arrived in. The box, UPC bar code, packaging, and all other accessories must be returned. Open software, music, games, movies, and personal hygiene products are not eligible for returns. ABOUT US We sell on eBay since 2002. We are based in the USA and ship from our own warehouses. Our products are a 100% authentic and all brand new. We work with the biggest suppliers in the US to bring you the best quality items you can get! We guarantee to provide the best service you have ever seen before
