T-8120 Preheating Oven Infrared Preheating Station

US $67.99

Guangzhou, China
Mar 3rd

Open on mobile:
QR code

T-8120 Preheating Oven NOTE: we don't ship the item to PO BOX address, and we only ship the item to English address, so please leave us your physical English address when you pay. Features: 1. The machine selects the infrared highly effective component to give off heat which independent exploration, adopt advanced PID intelligent controlling warm heating technology, controls warm precisely. 2. Can achieve to heat PCB board and component which contains lead or not,especially suit to BGA?SMD. 3. Use infrared heat, easy to cut through, heat proportion, don’t have sirocco flow. Don’t shift the small component on the PCB board,ensure the welding quality. 4. This machine has 600W heating system, widely to 120x120mm.Can use with the handhold infrared welder T-835. 5. Easily operate, can operate it through easy training. Parameter: Work floor size 200x240mm Rated voltage and frequency AC220-230v/AC110V 60/50Hz Complete machine power 800W Preheating chassis power 600W Preheating chassis size 120x120mm Preheating chassis temperature adjustable 0-450°C Main Component: Preheating oven main body 1 Temperature sensor 1 Board support of the circuit 1 Power line 1 User manual (compact disc) 1 Operation instructions: 1. Starting and inspects before starting: (1)Check the temperature sensor and the power line. (2)Turn on the power line. Don’t use until passing check. (The nixie tube displays the indoor temperature.) (3)The black switch on the front panel use to control the infrared preheating chassis; press “?”up,“?”down,can be at 0-450°C,adjust the infrared preheating chassis’s temperature. Press the button“WARM”,the infrared preheating chassis starts to work, press“COOL”,it stops working. 2.Operation of preheating PCB board: (1) PCB board’s placement and adjustment: (1)According to the PCB board’s size, adjust the location of the board support, put the PCB board on the support and fix the screw tightly with hands. Make the temperature measurement head fixed on the PCB board which needs to preheating, use aluminum-foil paper or adhesive paper to stick tightly. (2)According to the size of PCB board and welding technological requirement, press “?”and “?”button, between 0°C and 450°C, regulate the output temperature of preheating chassis. (2) Preheating opening and closure: (1)Press the “WARM” button,open the preheating chassis about 3-5 minutes, make the temperature be about the setting value then carry on the step operation. (2)After finishing ,press “COOL”, the preheating chassis stop working. Attention:This time can’ t close the power switch, after the machine full cooling then close the power source. (3)General preheating temperature establishment suggestion: when PCB board has lead ,may adjust the infrared preheating chassis temperature to 100-120°C ; When PCB board has non-lead, may adjust to 120-140°C ; Also may set the different preheating temperature voluntarily according to user's use craft and experience. 3. Machine installation and adjustment: This infrared preheating chassis heating way includes: The total pressure flow-through heating way and the PID percentage adjustment way, you may adjust voluntarily according to the PCB board’s preheating allowance. The general suggestion preheating temperature is lower than 250°C, selects the PID percentage adjustment method; The preheating temperature is higher than 250°C, use the total pressure flow-through heating way. Adjustment method: 1.press “?”power-on, display: C=? 2.press “?”choose 0 or 1,every press the status change one time, C=0 is PID percentage adjustment, C=1 is switching control. Caution! 1. After finishing, don’t turn off the power immediately; make the infrared preheating chassis full cooling. 2. Keep the ventilation free-flowing, the infrared preheating chassis pure; use the dehydrated alcohol to be clean regularly! 3. Careful, the high temperature operation, pay attention, avoids scalding. 4. Long-time doesn’t use, should cramp out the power source plug! Shipping terms Payment terms: 1. We accept Paypal only. 2. Payments must be finished within 5 working days after bid, otherwise, Unpaid Item dispute will be reported to eBay. Shipping terms: 1. We ship via EMS/DHL/UPS to the following countries: ?USA, Canada; ?Belgium, Netherlands, Luxembourg, Italy, Germany, France, United Kingdom, San Marino; ?Austria ,Denmark ,Finland ,Greece ,Ireland ,GUERNSEY ,JERSEY ,Norway , Portugal , spain , Sweden , Switzerland; ?Bulgaria,Cyprus,Estonia,Latvia,Lithuania,Malta,slovakia,slovenia; ?Czech Republic, Hungary, Poland, Romania,. ?Australia ,New Zealand ,Korea South, Malaysia, Thailand, Philippines ,Singapore , Bruniei ,Taiwan , Macau, Indonesia, If your country doesn’t belong to the countries we listed, please contact us for detailed freight before you biding. 2. we only ship the item to the papal address. So pls be sure you fill the shipping address the same as paypal address. PLS note: be sure leave us your cell phone number , so that the item can reach you quickly and smoothly. 3. Normally, It will take 7-10 working days to reach USA, Australia, Europe, other countries may a little longer. 4. We will declare the item as gift or sample with low value. However, Import duties, taxes and Charges are not included in the item price. The buyer is responsible for all the duty and local tax. Return Policy: 1. Upon receiving the item within 7 days, any defective item not due to misused will entitled to 1 to 1 exchange. please return it to us in the original condition and package. 2. If you need any assistance on your item problem please do not hesitate to contact us, our technical support will be there to assist you. Feedback We will very appreciate you give us positive feedback (5 star) ASAP. If the item you got in any problem, PLS don’t hesitates to contact us. We will do our best to help solve the problem.One negative feedback is kill us. So please before leaving feedback, if there is any problem, contact us to try to solve it! Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
