Taylor Dunn Utility Cart - 3 Wheel Service Manual Cd In Pdf.

US $15.00

Glasgow, Kentucky, United States
Jan 30th

Open on mobile:
QR code

Operation and Maintance Service Manual with Parts List For Model C 432 & C 433 - or also known as C4-32 & Model C4-33 Serial 94315 through 151285 . Taylor-Dunn Mfg. Co. Commerical and Indusrtrial Vehicles. Complete and In Good Condition . Electrical , Mechanical this Manual covers all parts of the Service Vehicle. Taylor-Dunn’s C-432 and C-433 have the shortest turning radius available in a sit-down combination burden carrier/tow tractor. With a 28” wheel base, these vehicles can maneuver into corners other powered trucks simply cannot reach – indoor or outdoor When versatility in load capacities, optional configurations, and performance are paramount to running your operations efficiently, you need to look no further than Taylor-Dunn's line of burden carriers. Taylor-Dunn burden carriers carry loads up to 6,400 lbs. and can tow loads up to 20,000 lbs. With unitized bodies, 16-gauge steel frames, and automotive differentials for strength and reliability, Taylor-Dunn burden carriers are the perfect answer to your material handling needs. .... Heavy-duty batteries, built-in fully-automatic chargers make sure these trucks are always ready to go. They are ideal for moving loads over smooth floors in warehousing, hospitals, schools and other environments where quiet fume free operation is necessary. Only 30 inches wide, these compact trucks clear narrow aisles and standard doorways. Full 360° turns can be made in a mere 140”. Adjustable seats and all-steel construction ensure a comfortable, safe ride. Individually padded seat and backrest are covered with tough heavy-duty vinyl upholstery. Bumpers are heavy-duty steel welded to the frame; 16 gauge steel diamond plate facing covers all exterior surfaces Accessories • Headlight, taillight • Hour meter • Light on top of cab • Stoplight • Windshield wiper • Mirrors • Reverse warning beeper Hitches • Hitch automatic coupling • Hitch pintle Cab • Fiberglass cab & vinyl doors Color • Special paint color • Undercoating Batteries • 244 ah batteries Tires • 16 1/4 x 4 x 11 1/4 extra cushion solid tires • Soft solid tires Brakes • Hydraulic Deck • Stake sides • Diamond plate deck Product Line: Model C-433 Wheels: 3 wheels Unit Weight: 826 lbs. (374 kg) Load Capacity: 1,200 lbs. Draw Bar Pull: 150 lbs Battery Type (Lead acid): 217 amp hour, 4 each System Voltage: 24 volt Travel Distance (Unloaded): 20 miles (32.2 km) Drive Axle: Automotive differential Transmission: “Power Traction” drive operating in oil bath, 14:1 reduction Motor: 6.0 HP Speed: 6.5 mph (10 km/h) standard (empty) Tires: 4.80 x 8 load range B Steering: Chain and sprocket reduction to front fork Brakes: Mechanical brake through differential to both rear wheels, hand operated parking brake Frame: All-steel unitized body and frame, heavy duty 16 gauge diamond plate facing on all exterior surfaces Bumper: Heavy duty steel, welded to frame Color: Safety orange Seat: Adjustable individual seat with backrest Controller: Solid state speed controller Instrumentation: Battery status indicator Horn: 12 volt electric horn Charger: Built-in, 24V, 600 watt, 110 VAC w/ interlock Conformance Standards: Type E OSHA requirements 1910.178, ANSI B56.8-1987 requirements Q: is it in good condition for moving parts A: Yes, It shows all the parts and shows assembly. Q: how long is it A: This Manual is 105 Pages long and covers the entire Cart, all parts are shown. Q. What Format is Manual A. Manual is on CD in Pdf format
