Tc 2.2kw 5a Frequency Inverter Converter General Vector Type 380v Ic+igbt Rs485

US $136.00

Guangzhou, China
Mar 3rd

Open on mobile:
QR code

High Quality 2.2KW Frequency Inverter Converter 380V 5A IC+IGBT RS485 PID WE HAVE inverters from 0.75-400kw, please contact us if any need. NOTE: we don't ship the item to PO BOX address, and we only ship the item to English address, s please leave us your physical English address when you pay. the item can only be used to motor speed regulation, input and output: 380v. Series technical index Input Nominal voltage?frequency 380V 50HZ/60HZ Range of voltage changes ±15% Output Range of frequency 0.10~400.00HZ Overload range 150% 1min Frequency control Control mode SPWM precision digital:0.01% analog:0.1% Setting resolution digital:0.01HZ;analog: 0.1% of max operation frequency Output resolution 0.01HZ Set way of frequency keyboard,0~5V,0-10V,4-20mA,0-20MA Other function Upper/lower limit of frequency, start frequency, stop frequency, set the 3 hopping frequency separately Control feature acceleration and deceleration control Arbitrary selection of 4 acceleration and deceleration time(1.0-6500sec) V/F curve Arbitrary setting of V/F curve Torque control Torque boost setting,max10%,start torque at 1.0HZcan reach 150% Multifunction input end 6 multifunction input end to control 8 period of speed control, program run,4period of switch back to speed, UP?DOWN function,counter,external scram and so on Multifunction output end 5 multifunction output end to control the indication and warning during run?0 speed?counter?external exception?program run and so on Energy-conservation control Automate put out voltage at high-speed according to the load to make sure the max efficiency of the motor Ultra-silence Carrier frequency can reach 20KHZ PID Built-in PID function Simple PLC Form self-control 8 period speed to run, arbitrary setting of run time and way Com port Standard RS485 port Other function AVR?slow down to stop,free parking operation,DC brake,automatic reset and start again,frequency tracking,PLC?traverse control?adjust carrier,max 20KHZ,draft and so on Monitor function 5 digital display,showing frequency?current?rotate speed?hi-DC?output voltage?count value?temperature?state of pos and cons,fault displayand so on vibration Under 0.5G Operation temperature -10-40°C humidity 0-95%,with no moisture condensation Protection function Overload protection Electronic relay protection of motor,actuator(constant torque 150%/1min,fan type 120%/1min) FUSE protection FUSE and motor stops overvoltage 220V class: DC>400V;380V class:DC>800V undervoltage 220Vclass:DC<200V;380Vclass:DC<400V Instantaneous power to start again Instantaneous power to start again by frequency tracking Stall to prevent stall to prevent during add/deceleration Output short circuit Electronic circuit protection Other function Fin overheating protection, reverse restriction, failure reset, data lock and so on. Shipping Policy: We will send out the item within 3-5 working days through DHL/EMS/FEDEX to the below countries: Belgium, Netherlands, Luxembourg, Italy, Germany, France, United Kingdom, San Marino; Austria ,Denmark ,Finland ,Greece ,Ireland ,GUERNSEY ,JERSEY ,Norway , Portugal , spain , Sweden , Switzerland; Bulgaria,Cyprus,Estonia,Latvia,Lithuania,Malta,slovakia,slovenia; Czech Republic, Hungary, Poland, Romania,. Australia ,New Zealand ,Korea South, Malaysia, Thailand, Philippines ,Singapore , Bruniei ,Taiwan , Macau, Indonesia, USA, Canada Please note: we do’t ship the item to the countries not belong to the above list. pls check if your country in the list before you diding. We will send tracking number to your eBay email within 1 day after sending out your item We will declare the item as gift or sample with low value. However, Import duties, taxes and Charges are not included in the item price. The buyer is responsible for all the duty and local tax. Payment policy: We accept Paypal only. Payments must be finished within 5 working days after bid, otherwise, Unpaid Item dispute will be reported to eBay. Refund &Return policy: We take all the responsibility during delivery. If you do not receive your item, we will refund you the full money or send you a new item according to your request. We can accept the return item within 60 days after the buyer receives it. Once we receive the return item, then we will refund you full money. Feedback Policy: We will very appreciate you give us positive feedback (5 star) ASAP. If the item you got in any problem, PLS don’t hesitates to contact us. We will do our best to help solve the problem Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
