Tcrt5000 Track Sensor Brick

AU $2.90

Sydney, Australia
Jun 9th

Open on mobile:
QR code

Overview TCRT5000 based track sensor emits and receives infrared signals. When used within a certain height range, the control board can detect whether there are objects blocking via digital pins. Track sensors are widely used in smart cars or printers for black and white line detection. DESCRIPTION What is an electronic brick? An electronic brick is an electronic module which can be assembled like Lego bricks simply by plugging in and pulling out. Compared to traditional universal boards and circuit modules assembled with various electronic components, electronic brick has standardized interfaces, plug and play, simplifying construction of prototype circuit on one’s own. There are many types of electronic bricks, and we provide more than twenty types with different functions including buttons, sensors, Bluetooth modules, etc, whose functions cover from sensor to motor drive, from Ethernet to wireless communication via Bluetooth, and so on. We will continue to add more types to meet the various needs of different projects. Electronic brick of track sensor is based on sensor TCRT5000, which is to receive the returned infrared signals after sending out to detect the signal strength. Within a certain height range, the control board can detect whether there are objects blocking via digital pins . Track sensors are widely used in smart cars or printers for black and white line detection. Feature 1. Plug and play, easy to use. Compatible with the mainstream 2.54 interfaces and 4-Pin Grove interfaces in the market. 2. With use of M4 standard fixed holes, compatible with M4-standard kits such as Lego and Makeblock. 3. With adjustable potentiometer to set detecting height threshold. 4. With hysteresis comparison circuit for more stable digital output voltage 5. With LED indicator for real-time detection of current digital output status. Specifications PCB size 48.0mm X 13.00mm X 1.6mm Working voltage 3.3 or 5V DC Operating voltage 3.3 or 5V DC Compatible interfaces 2.54 3-pin interface and 4-pin Grove interface(1) Detecting height range 0-50mm(2) Note 1: S for analog/digital output port ( defined according to the switch), V and G for voltage at the common collector and ground respectively Note 2: The specific measurable height is depended on the color and reflection of the material, the more the color contrast, the better to detect. Electrical characteristics Parameter Min. Typical Max. Unit Working voltage 2.1 5 5.5 VDC Digital output voltage (VCC=5V) 0 - 5 V Working current (VCC=5V) - 38 - mA Threshold hysteresis ΔUth - VCC*0.09 - V Detecting height range (VCC=5V, Vth=3.5V) 0 - 50 mm Hardware Switch and indicator 1. Regulating of threshold voltage: The threshold voltage is a voltage for comparison. When the sensor encounters obstacles, and the induced voltage is above the threshold, it will digitally output a high level (3.3V or 5V); when there are no obstacles, and the induced voltage is below the threshold, it will digitally output a low level (0V). In this way, the digital pin can be used directly to see if the sensor encounters obstacles or not. The threshold voltage can be regulated by simply twisting the potentiometer which is shown in the following diagram, and it increases by rotating to left side and decreases by rotating to right side 2. Status lamp Within certain height, LED lamp will be OFF when obstacles or non-black objects are detected and it will be ON when no obstacles but black objects (compared to the non-black objects under the same height) are detected. DEMO Connect S port of track sensor to D2 port of Arduino board, and we will use the following program to read the digital value of current status. When objects are detected, buzzer will give an alarm. const int DSIGNAL = 2; const int buzzer= 3; void setup() { pinMode(DSIGNAL, INPUT); } void loop() { int DsignalState = digitalRead(DSIGNAL); if(DsignalState) { digitalWrite(buzzer,LOW); } else { digitalWrite(buzzer,HIGH); } } Revision history Version Description Date Written by v1.0 Initial edition 18th, April, 2013 Stan Lee Specification Brick Type Sensor Brick Brick Interface 3PIN Brick Power Supply 5V Board Size 48 x 13 x 1.6mm LED Color No Weight 15.00g Model IM121012001 Links MotoMama And Makeblock 2WD Robot Kit Download Schematic SCH_IM121012001 Datasheet DS_IM121012001 Demo Code DEMO_IM121012001
