Tektronix 1240 Logic Analyzer 1240d2 Data Acquisition Cards 72 Channels Working

US $310

Red Bank, New Jersey, United States
May 27th

Open on mobile:
QR code

1240 LOGIC ANALYZER with FOUR 1240D2 DATA ACQISITION CARDS for a total of 72 CHANNELS Here is an auction for a used TEKTRONIX 1240 Logic Analyzer. This fantastic intrument provides total performance analysis for hardware, software and integration applications. For analysis the 1240 offers up to 72 channels of acquisition at sampling rates of 100 MHz with 6 ns glitch detection. Superior hardware triggering capabilities include data & glitch triggering for isolating problems; clocked & unclocked triggering for capturing events. There are 14 levels of triggering with conditional branching for unmasking the most gnarly problems. Featuring easy setup and simple menu operation with on-screen touch soft keys makes using this item a snap. This instrument was fully functional when removed from a working environment and is is in very good condition. It is fully loaded with four 1240D2 cards to provide 72 channels of acquisition. Being a used item there will be some scratches & dings but nothing that affects the operation. The item powers up, passes all self tests (including I/O, Frontpanel, Display, Control, Trigger and all four 1240D2 Cards) and goes through all menues as expected (see photo's below). I am unable to do a detailed performance evaluation of this instrument but I did perform a simple logic analysis and the item triggered properly and displayed the results. See the photo below for the results of this test. This item is guaranteed to power up and function as described. FEATURES TOTAL DESIGN SUPPORT: HARDWARE, SOFTWARE & INTEGRATION 72 ACQUISITION CHANNELS ACQUISITION SPEEDS TO 100 MHz ASYNC, 50 MHz SYNC 14 LEVELS OF TRIGGERING WITH CONDITIONAL BRANCHING DUAL TIME BASE TRIGGERING, ACQUISITION, AND DISPLAY SIMPLE MENU OPERATION WITH ON-SCREEN SOFT TOUCH KEYS TRANSFERS EASILY INTO MANUFACTURING & SERVICE Includes manual set on CDROM & power cord. CLICK HERE FOR FULL SPECS. PLEASE SEE MY OTHER AUCTIONS FOR ADDITIONAL 1240 ITEMS INCLUDING ROM PACKS, PROBES, MICROPROCESSOR SUPPORT, ETC. PASSES ALL POWER UP DIAGNOSTIC TESTING GOES THROUGH MENUS AS EXPECTED, TOUCH SCREEN WORKS, THIS IS CONFIG MENU THIS IS TRIGGER MENU DATA MENU EDIT MENU SUCCESSFULLY TRIGGERS ON AN EVENT PRESENTING THE DATA AS TIMING DIAGRAM THE "FINE PRINT" I very much appreciate your viewing my auctions and will do my best to be sure you are happy with your purchases Winners of multiple auctions may be able to combine items into one package to save shipping costs Please note that due to size, destination and shipping service this may not always be possible but I will bry my best Shipping Insurance not included in postage - if you wish the item to be insured please notify me before paying I expect payment within 3 days of the close of the auction I reserve the right to terminate the auction and relist the item if payment is not received in a timely manner I reserve the right to refuse to sell to buyers with low or excessive negative feedback I leave positive feedback for good customers and appreciate positive feedback from satisfied customers NOTHING is included other than what is EXPLICITLY pictured and described in the listing Please email before auction ends if you have questions as to what IS included and NOT included I cannot be responsible if you mistakenly assume items are included other than what is specifically described INTERNATIONAL CUSTOMERS WELCOME Note that we must provide accurate information on customs forms please do not ask us to do otherwise as that constitutes fraud and is against eBay policy Shipping costs are calculated as USPS PRIORITY MAIL INTERNATIONAL We cannot be responsible for shipping delays caused by shipping worldwide as we have no control over the shippers Note that any import duties, taxes and charges ARE NOT INCLUDED in the item price or shipping cost These charges are the buyers responsibility - Please check with your contry's customs office to determine what these additional costs will be PRIOR to bidding or buying These charges are normally collected by the delivering freight (shipping) company or when you pick the item up. DO NOT confuse them for additional shipping charges It is assumed that if you purchase this item you are aware of these charges and your responsibility to pay them Item is guaranteed to be as pictured and described Returns are accepted ONLY if the item was not as described in the auction Postage not refundable on returned items I will consider, but cannot guarantee, LOCAL PICKUP for this item Please contact me before auction ends if this is an important factor in your purchase View my other auctions
